TSSOP14 SSOP14 - 0.65mm - Body 4.4mm - ZIF Socket

The TSSOP14 SSOP14 ZIF Socket is designed for secure and convenient connections with integrated circuits featuring a 0.65mm pitch and a 4.4mm body width. This component facilitates easy insertion and removal of devices without soldering, making it ideal for testing, programming, or prototyping applications in electronics development. Its Zero Insertion Force design ensures reliable contact while protecting delicate pins from damage, supporting compatibility with a wide range of TSSOP14 and SSOP14 packaged ICs.

• Zero Insertion Force mechanism allows effortless chip placement and removal, reducing wear on pins during repetitive testing.
• 0.65mm pin pitch precisely matches the standard TSSOP14 and SSOP14 integrated circuit layouts for optimal connection.
• Compact 4.4mm body width fits tightly within typical PCB footprints for these package types, saving board space.
• Durable contacts provide consistent electrical performance across numerous insertion cycles.
• Versatile use for device programming, verification, and troubleshooting in electronics manufacturing and development.
• Compatible with standard TSSOP and SSOP chips, supporting various semiconductor manufacturers’ devices.
• Reduces soldering requirements thereby speeding up prototyping and reducing risk of component damage.
