Product Description

The Amass Anti Spark AS150S Male Connector (AS150S-M.G.B) is a premium-grade high-current anti-spark DC power connector designed for safe and reliable power connection in agriculture drones, industrial UAV systems, RC vehicles, electric mobility solutions, robotics, and high-capacity lithium battery packs. Manufactured by Amass, a globally recognized leader in professional connector technology, the AS150S series is engineered to solve one of the biggest problems in high-power systems—sparking during battery connection.

The AS150S-M.G.B Male Connector features a built-in anti-spark (pre-charge) design, which reduces inrush current when connecting high-voltage lithium battery systems. This helps prevent damaging electrical arcs, protects sensitive electronics like ESCs and BMS units, and improves the overall safety of the power system. It is especially useful in 12S–14S drone and UAV battery setups, where connection sparks can otherwise damage connector surfaces over time.

The connector uses precision-machined brass contacts with gold plating, ensuring excellent conductivity, very low resistance, and stable high-current performance. The gold plating also improves corrosion resistance, allowing long-term durability even under frequent connection cycles and harsh outdoor conditions.

Designed for high-power applications, the AS150S connector supports approximately 75A continuous current and up to 150A peak capability (depending on system design and wire gauge), making it suitable for heavy-duty UAV propulsion systems and industrial battery packs. It is also rated for 500V DC operation, making it compatible with modern high-voltage drone architectures.

The housing is made from high-temperature PA66 (Nylon) thermoplastic with flame-retardant properties, offering excellent insulation, mechanical strength, and thermal stability. The rugged design ensures resistance against vibration, shock, and environmental stress—critical for drones and mobile robotics operating in real-world conditions.

A key highlight of this connector is its anti-spark resistor-based pre-charge system, which gradually equalizes voltage during connection. This significantly reduces stress on capacitors in ESCs and BMS systems, improving overall system lifespan and safety.

Whether you're building an agricultural drone, assembling a high-voltage battery pack, or working on industrial robotics, the Amass AS150S Male Connector provides a safer, more reliable alternative to standard high-current connectors.

Key Features

• Genuine Amass AS150S-M.G.B Anti-Spark Male Connector
• Built-in anti-spark (pre-charge) safety technology
• Gold-plated brass contact for excellent conductivity
• Low contact resistance for efficient power transfer
• High-current capability up to ~75A continuous / 150A peak
• Rated for 500V DC systems
• High-temperature PA66 UL94 V-0 flame-retardant housing
• Reduces electrical arcing during connection
• Protects ESCs, BMS, and battery systems from inrush damage
• Strong vibration-resistant friction-fit design
• Durable and long service life

Applications & Use Cases

• Agriculture drones and spraying UAVs
• Heavy-lift industrial drones (VTOL systems)
• High-voltage lithium battery packs (12S–14S setups)
• Battery-to-ESC power connections
• Electric vehicles and e-mobility systems
• Robotics and automation systems
• Industrial power distribution units
• High-current charging systems
• RC aircraft, boats, and ground vehicles
• Professional UAV power systems

Technical Specifications

• Brand: Amass
• Model: AS150S-M.G.B
• Connector Type: Male
• Series: AS150S (Anti-Spark)
• Contact Material: Brass, gold-plated
• Housing Material: PA66 (Nylon), UL94 V-0 flame-retardant
• Rated Current: ~75A continuous (up to 150A peak)
• Rated Voltage: 500V DC
• Wire Compatibility: Up to 6–8 AWG
• Mechanical Life: ~100 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Solder wire connection
• Protection Level: IP40 (typical)

Why Choose This Connector?

The Amass AS150S Anti-Spark Connector is specifically designed for users who work with high-voltage and high-capacity battery systems, where safety and reliability are critical. Unlike standard connectors, it actively reduces spark formation during connection, protecting both hardware and connectors from long-term damage.

This makes it a preferred choice for professional UAV manufacturers, EV builders, and advanced robotics systems where stable power delivery and safety cannot be compromised.

Package Includes

• 1 × Amass AS150S-M.G.B Anti-Spark Male Connector

Product Description

The Amass XT60H Male Connector with Housing (XT60H-M.G.Y) is a next-generation high-current 2-pin DC power connector designed for safe, reliable, and efficient power delivery in drones, RC vehicles, robotics, battery packs, electric vehicles, and industrial electronic systems. Manufactured by Amass, a globally trusted leader in connector technology, the XT60H series is an upgraded version of the classic XT60, offering improved ergonomics, better safety, and enhanced mechanical durability.

The XT60H-M.G.Y Male Connector features precision gold-plated brass contacts, ensuring excellent electrical conductivity and very low contact resistance. This helps reduce power loss and heat generation during high-current operation, making it suitable for demanding applications such as UAV propulsion systems and lithium battery power distribution. The gold plating also provides strong resistance to oxidation and corrosion, ensuring consistent long-term performance.

A key improvement in the XT60H design is its integrated protective housing (“H” series design), which not only strengthens the connector body but also protects solder joints and improves handling. The ergonomic grip makes plugging and unplugging easier and more secure, especially in field applications like drone maintenance and RC setups.

The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, ensuring excellent insulation, mechanical strength, and thermal stability. This rugged construction allows the connector to withstand vibration, shock, and continuous electrical stress in harsh operating environments.

Designed for high-current battery systems, the XT60H connector typically supports up to 60A peak current (with lower continuous ratings depending on wire and cooling conditions) and operates safely in up to 500V DC systems. It is widely used in drone power systems, ESC connections, and lithium battery packs where stable and compact power delivery is essential.

Whether you're building an FPV drone, assembling a robotics platform, or working on battery-powered electronics, the Amass XT60H Male Connector with Housing delivers a reliable balance of performance, safety, and compact design.

Key Features

• Genuine Amass XT60H-M.G.Y Male Connector
• Upgraded XT60 series with protective housing design
• Gold-plated brass contacts for excellent conductivity
• Low contact resistance for efficient power transfer
• Integrated grip housing for easy handling
• High-temperature PA (Polyamide) UL94 V-0 flame-retardant shell
• Secure friction-fit connection system
• Improved protection for solder joints
• Compact and lightweight design
• Excellent vibration and heat resistance
• Long service life with stable performance

Applications & Use Cases

• FPV racing drones and UAV systems
• Agricultural and industrial drones
• Lithium battery packs (LiPo/Li-ion)
• Electronic Speed Controllers (ESCs)
• Power Distribution Boards (PDBs)
• RC cars, boats, and aircraft
• Robotics and automation systems
• DIY electronics and prototyping
• Battery charging systems
• Embedded power electronics
• Industrial control systems

Technical Specifications

• Brand: Amass
• Model: XT60H-M.G.Y
• Connector Type: Male
• Series: XT60H
• Number of Pins: 2
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Voltage: 500V DC
• Current Rating: ~30A continuous / up to ~60A peak (application dependent)
• Wire Compatibility: 12–14 AWG
• Operating Temperature: -20°C to 120°C
• Mechanical Life: ~100 mating cycles (typical)
• Mounting Type: Solder wire connection

Why Choose This Connector?

The Amass XT60H Male Connector is ideal for users who need a safer and more user-friendly upgrade over the standard XT60 connector. Its integrated housing improves handling, protects solder joints, and reduces wear during repeated use.

Compared to older XT60 designs, the XT60H series offers better ergonomics, improved mechanical protection, and more reliable real-world performance, making it a preferred choice for modern drone and battery-powered systems.

Package Includes

• 1 × Amass XT60H Male Connector with Housing (XT60H-M.G.Y)

Product Description

The Amass Anti Spark AS150S Male Connector (AS150S-M.G.R) is a premium high-current anti-spark DC power connector designed for safe and reliable power connection in agriculture drones, industrial UAVs, RC aircraft, electric vehicles, robotics, and high-capacity lithium battery systems. Manufactured by Amass, a globally recognized leader in connector technology, the AS150S series is engineered specifically to reduce dangerous electrical arcing during battery connection, improving both system safety and connector lifespan.

The AS150S-M.G.R Male Connector features a built-in anti-spark (pre-charge) resistor design, which controls inrush current when connecting high-voltage battery packs. This prevents the sudden electrical “pop” or spark that typically occurs in high-capacity lithium systems, especially in 12S–14S UAV and drone configurations. By gradually charging system capacitors, it protects sensitive components such as ESCs, BMS units, and power distribution boards from electrical stress.

The connector uses a 7mm gold-plated brass bullet contact, ensuring excellent conductivity, low resistance, and stable high-current performance. The gold plating helps resist oxidation and corrosion, allowing consistent performance over long-term use and repeated mating cycles. This makes it highly suitable for demanding outdoor applications such as agricultural spraying drones and industrial UAV systems.

Designed for high-power applications, the AS150S connector supports approximately 75A continuous current and up to 150A peak current (depending on wiring and cooling conditions), making it suitable for heavy-duty power systems. It is also rated for up to 500V DC systems, ensuring compatibility with modern high-voltage drone architectures.

The housing is made from high-temperature PA66 (Nylon) thermoplastic with UL94 flame-retardant properties, offering excellent insulation, mechanical strength, and thermal stability. Its rugged construction ensures resistance to vibration, shock, and harsh operating conditions commonly found in UAVs and mobile robotics.

The AS150S series is widely used because of its patented anti-spark design, which significantly improves safety during battery connection and reduces long-term wear on connector surfaces.

Whether you're building a professional drone system, designing a high-voltage battery pack, or working on industrial robotics, the Amass AS150S Male Connector provides a safer, more durable, and high-performance power connection solution.

Key Features

• Genuine Amass AS150S-M.G.R Anti-Spark Male Connector
• Built-in anti-spark (pre-charge resistor) technology
• Gold-plated 7mm brass bullet contact for high conductivity
• Low contact resistance for efficient power transfer
• Reduces electrical arcing during battery connection
• Supports ~75A continuous / up to 150A peak current
• Rated for 500V DC systems
• High-temperature PA66 UL94 flame-retardant housing
• Strong vibration-resistant friction-fit design
• Protects ESCs, BMS, and battery systems
• Long service life with stable performance

Applications & Use Cases

• Agriculture drones and spraying UAVs
• Heavy-lift industrial drones (VTOL systems)
• High-voltage lithium battery packs (12S–14S setups)
• Battery-to-ESC power connections
• Electric vehicles and e-mobility systems
• Robotics and automation systems
• Industrial power distribution units
• RC aircraft, boats, and ground vehicles
• High-current charging systems
• Professional UAV power architectures

Technical Specifications

• Brand: Amass
• Model: AS150S-M.G.R
• Connector Type: Male
• Series: AS150S (Anti-Spark)
• Contact Material: Brass, gold-plated
• Housing Material: PA66 (Nylon), flame-retardant
• Rated Current: ~75A continuous (up to 150A peak)
• Rated Voltage: 500V DC
• Wire Compatibility: Up to 6–8 AWG
• Mechanical Life: ~100 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Solder wire connection
• Protection Level: IP40

Why Choose This Connector?

The Amass AS150S Anti-Spark Connector is designed for users who work with high-voltage drone and battery systems where safety is critical. Unlike standard connectors, it actively prevents spark formation during connection, protecting both electronics and connectors from long-term damage.

This makes it especially valuable for professional UAV builders and industrial power system designers, where reliability, safety, and durability are non-negotiable.

Package Includes

• 1 × Amass AS150S-M.G.R Anti-Spark Male Connector

Product Description

The Amass XT150 Female Connector (XT150-F.G.BL) is a premium high-current single-pin DC power connector designed for demanding applications such as agriculture drones, industrial UAV systems, RC vehicles, electric mobility solutions, robotics, and high-capacity lithium battery packs. Manufactured by Amass, a globally recognized leader in connector technology, the XT150 series is engineered for stable high-current transfer, low resistance, and long-term durability in harsh operating environments.

The XT150-F.G.BL Female Connector features a precision-machined brass contact with gold flash plating, ensuring excellent electrical conductivity and very low contact resistance. This helps reduce energy loss and heat generation during continuous high-load operation, making it suitable for professional UAV and battery power systems. The gold plating also improves resistance to oxidation and corrosion, ensuring consistent performance over repeated mating cycles.

Designed for high-power DC applications, the XT150 connector supports approximately 60A continuous current (depending on wire gauge and thermal conditions) and can handle high peak currents for short bursts, making it suitable for drone propulsion systems and heavy battery loads. It is rated for up to 500V DC systems, allowing compatibility with a wide range of industrial and UAV electronics.

The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and thermal stability. This rugged construction ensures safe operation under vibration, shock, and continuous electrical stress, which is critical for UAVs and mobile robotic platforms.

A key advantage of the XT150 series is its large contact surface area design, which improves current handling capability and reduces resistance compared to smaller connector types. This makes it especially useful for high-power battery packs and ESC connections where efficiency and thermal management are important.

Whether you're building an agricultural drone, assembling a high-capacity battery system, or working on industrial electronics, the Amass XT150 Female Connector delivers reliable performance, strong mechanical durability, and efficient power transmission.

Key Features

• Genuine Amass XT150-F.G.BL Female Connector
• High-current single-pin DC power connector
• Gold flash plated brass contact for excellent conductivity
• Low contact resistance for efficient energy transfer
• Supports ~60A continuous current (application dependent)
• Rated for up to 500V DC systems
• High-temperature PA (Polyamide) UL94 V-0 flame-retardant housing
• Secure friction-fit connection for vibration resistance
• Large contact surface for improved current handling
• Durable construction for long service life
• Easy solder-type wire termination

Applications & Use Cases

• Agriculture drones and spraying UAVs
• Heavy-lift industrial UAV systems
• Lithium-ion and LiPo battery packs
• Battery-to-ESC power connections
• RC cars, boats, and aircraft
• Robotics and automation systems
• Industrial power distribution systems
• Electric vehicles and mobility systems
• High-current charging systems
• DIY electronics and prototyping

Technical Specifications

• Brand: Amass
• Model: XT150-F.G.BL
• Connector Type: Female
• Series: XT150
• Contact Material: Brass, gold flash plated
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Current: ~60A continuous
• Rated Voltage: 500V DC
• Wire Compatibility: Up to 8 AWG
• Mechanical Life: ~1000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Solder wire connection
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT150 Female Connector is designed for users who need a high-current, low-loss, and mechanically strong power connector for professional applications. Its large contact design ensures stable current flow, while the rugged housing ensures durability in demanding environments.

Compared to smaller XT-series connectors, the XT150 offers higher current capacity, better thermal handling, and stronger mechanical robustness, making it ideal for heavy-duty drone and power systems.

Package Includes

• 1 × Amass XT150 Female Connector (XT150-F.G.BL)

Product Description

The Amass XT60L Male Connector (XT60L-M.G.Y) is a high-performance 2-pin DC power connector designed for secure and efficient power transmission in drones, RC vehicles, robotics, battery packs, electric vehicles, and industrial electronic systems. Manufactured by Amass, a globally trusted brand in connector technology, the XT60L series is engineered as a compact, improved variant of the standard XT60, offering reliable connectivity, strong mechanical durability, and stable electrical performance.

The XT60L-M.G.Y Male Connector features precision gold-flash plated brass contacts, ensuring excellent conductivity and low contact resistance. This helps reduce power loss and heat buildup during high-current operation, making it suitable for UAV power systems, lithium battery packs, and ESC connections. The gold plating also provides corrosion resistance, ensuring long-term stability even under repeated connection cycles and outdoor usage conditions.

The XT60L series is known for its streamlined body design with improved grip and reduced size profile, making it easier to install in compact drone frames and tightly packed electronics. It maintains full compatibility with the XT60 ecosystem while offering a slightly more efficient mechanical layout for modern UAV and RC builds.

The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and thermal stability. This ensures safe operation under vibration, shock, and continuous electrical load conditions commonly found in drones and robotics.

Designed for medium-to-high current applications, the XT60L connector supports approximately 35A continuous current (depending on wire gauge and cooling conditions) and operates safely in up to 500V DC systems, making it ideal for drone propulsion systems and battery interfaces.

Whether you're building an FPV drone, assembling a robotics platform, or designing battery-powered electronics, the Amass XT60L Male Connector offers a dependable balance of size, performance, and durability.

Key Features

• Genuine Amass XT60L-M.G.Y Male Connector
• Compact XT60 series variant with improved design
• Gold-flash plated brass contacts for excellent conductivity
• Low contact resistance for efficient power transfer
• High-temperature PA (Polyamide) UL94 V-0 housing
• Secure friction-fit connection system
• Compact and lightweight body for tight installations
• Resistant to vibration, shock, and heat
• Compatible with XT60 ecosystem connectors
• Easy solder-type wire termination
• Long service life with stable performance

Applications & Use Cases

• FPV racing drones and UAV systems
• Agricultural and industrial drones
• Lithium battery packs (LiPo/Li-ion)
• Electronic Speed Controllers (ESCs)
• Power distribution systems (PDBs)
• RC cars, boats, and aircraft
• Robotics and automation systems
• DIY electronics and prototyping
• Battery charging systems
• Embedded power electronics
• Industrial control systems

Technical Specifications

• Brand: Amass
• Model: XT60L-M.G.Y
• Connector Type: Male
• Series: XT60L
• Number of Pins: 2
• Contact Material: Brass, gold-flash plated
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Current: 35A max (12AWG, thermal dependent)
• Rated Voltage: 500V DC
• Wire Compatibility: Up to 12–14 AWG
• Operating Temperature: -20°C to 120°C
• Mechanical Life: ~100 mating cycles
• Mounting Type: Solder wire connection
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT60L Male Connector is ideal for users who want a compact and reliable alternative to standard XT60 connectors, especially in space-constrained drone and robotics builds. It delivers stable current handling with improved mechanical design and long-term durability.

Compared to generic connectors, the XT60L series offers better build quality, safer electrical performance, and stronger reliability, making it a preferred choice for professional UAV and electronics applications.

Package Includes

• 1 × Amass XT60L Male Connector (XT60L-M.G.Y)

Product Description

The Amass XT60L Female Connector (XT60L-F.G.Y) is a high-quality 2-pin DC power connector designed for efficient, secure, and reliable power transmission in drones, RC vehicles, robotics, battery packs, electric vehicles, and industrial electronic systems. Manufactured by Amass, a globally trusted connector brand, the XT60L series is an upgraded and compact variant of the standard XT60, offering improved mechanical design and consistent electrical performance for modern UAV and electronics applications.

The XT60L-F.G.Y Female Connector features precision gold-flash plated brass contacts, ensuring excellent conductivity and low contact resistance. This helps reduce power loss and heat generation during high-current operation, making it suitable for UAV propulsion systems, lithium battery packs, and ESC power connections. The gold flash plating also provides strong resistance to oxidation and corrosion, ensuring long-term reliability even under frequent use and harsh environmental conditions.

Designed as part of the XT60L compact series, this connector offers a space-optimized body structure while maintaining full compatibility with XT60 systems. Its streamlined design makes it ideal for installations where space is limited, such as compact drone frames, tight battery compartments, and embedded electronic assemblies.

The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and thermal stability. This ensures safe operation under vibration, shock, and continuous electrical load conditions commonly found in UAV and robotics applications.

The XT60L connector is commonly rated for around 30A continuous current and up to 500V DC systems, depending on wire gauge and thermal conditions, making it suitable for medium-power drone and battery applications. Its reliable friction-fit design ensures a secure connection while still allowing easy disconnection when needed.

Whether you're building an FPV drone, assembling a robotics system, or working on battery-powered electronics, the Amass XT60L Female Connector provides a dependable balance of compact size, durability, and efficient power handling.

Key Features

• Genuine Amass XT60L-F.G.Y Female Connector
• Compact XT60 series variant with optimized body design
• Gold-flash plated brass contacts for high conductivity
• Low contact resistance for efficient power transfer
• High-temperature PA (Polyamide) UL94 V-0 flame-retardant housing
• Secure friction-fit connection system
• Space-saving design for compact electronics
• Resistant to vibration, heat, and mechanical stress
• Compatible with XT60 ecosystem connectors
• Easy solder-type wire termination
• Long service life with stable electrical performance

Applications & Use Cases

• FPV racing drones and UAV systems
• Agricultural and industrial drones
• Lithium battery packs (LiPo/Li-ion)
• Electronic Speed Controllers (ESCs)
• Power distribution systems (PDBs)
• RC cars, boats, and aircraft
• Robotics and automation systems
• DIY electronics and prototyping
• Battery charging systems
• Embedded power electronics
• Industrial control systems

Technical Specifications

• Brand: Amass
• Model: XT60L-F.G.Y
• Connector Type: Female
• Series: XT60L
• Number of Pins: 2
• Contact Material: Brass, gold-flash plated
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Current: ~30A continuous (application dependent)
• Rated Voltage: 500V DC
• Wire Compatibility: 12–14 AWG
• Operating Temperature: -20°C to 120°C
• Mechanical Life: ~100–1000 mating cycles (typical)
• Mounting Type: Solder wire connection
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT60L Female Connector is ideal for users who want a compact, reliable, and efficient alternative to standard XT60 connectors. It provides stable current handling while improving space efficiency and mechanical integration in modern drone and electronics designs.

Compared to generic connectors, the XT60L series offers better build quality, consistent conductivity, and improved durability, making it a strong choice for professional UAV and embedded power systems.

Package Includes

• 1 × Amass XT60L Female Connector (XT60L-F.G.Y)

Product Description

The Amass XT60IE-M Battery Connector (XT60IE-M.G.B) is a high-quality 2-pin DC power connector with integrated panel-mount and safety-oriented design, built for reliable power transmission in drones, RC systems, robotics, battery packs, electric vehicles, and industrial electronic applications. Manufactured by Amass, a globally trusted leader in connector technology, the XT60IE series is engineered to deliver stable current flow, low resistance, and secure mechanical installation for professional electronic systems.

The XT60IE-M.G.B Male Connector features precision gold-flash plated brass contacts, ensuring excellent conductivity and reduced contact resistance. This helps minimize power loss and heat generation during operation, making it suitable for medium-to-high power UAV systems and lithium battery applications. The gold plating also enhances corrosion resistance, ensuring long-term reliability even in harsh outdoor environments.

The XT60IE series is a panel-mount variant of the XT60 family, designed with a 3-pin (2+1 structure in some variants) and flange mounting system, allowing secure installation onto enclosures, battery housings, or power distribution units. This makes it especially useful for systems where a fixed, stable power input/output port is required rather than loose inline connectors.

The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, ensuring excellent insulation, mechanical strength, and thermal stability. It is designed to withstand vibration, shock, and continuous electrical stress, which is critical for drones and robotics applications.

The XT60IE series is typically rated for around 30A continuous current and up to 500V DC operation, depending on configuration and wiring conditions, making it suitable for UAV power systems and medium-load battery interfaces.

Whether you're designing a drone power input port, building a robotics charging interface, or assembling an embedded power system, the Amass XT60IE-M Battery Connector provides a reliable, safe, and professional-grade solution for fixed power connectivity.

Key Features

• Genuine Amass XT60IE-M.G.B Battery Connector
• Panel-mount XT60 series connector with flange design
• 2-pin / 3-pin (2+1 structure depending on variant) design
• Gold-flash plated brass contacts for high conductivity
• Low contact resistance for efficient power transfer
• High-temperature PA (Polyamide) UL94 V-0 flame-retardant housing
• Secure screw/flange mounting for stable installation
• Resistant to vibration and mechanical stress
• Compact and lightweight panel interface design
• Easy solder-type wire termination
• Long service life with consistent performance

Applications & Use Cases

• Drone battery input/output ports
• UAV charging and power distribution systems
• RC cars, boats, and aircraft
• Robotics and automation systems
• Battery management systems (BMS)
• Power distribution panels and chargers
• Embedded electronics and control systems
• DIY electronics and prototyping projects
• Industrial power interfaces
• Lithium battery pack connectors

Technical Specifications

• Brand: Amass
• Model: XT60IE-M.G.B
• Connector Type: Male
• Series: XT60IE (Panel Mount)
• Contact Material: Brass, gold-flash plated
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Current: 30A continuous (application dependent)
• Rated Voltage: 0.6kV / 500V DC
• Wire Compatibility: Up to 12 AWG
• Mechanical Life: ~1000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Panel mount (flange with screw holes)
• Electrical Connection: Solder termination

Why Choose This Connector?

The Amass XT60IE-M Battery Connector is ideal for users who need a fixed, panel-mounted XT60-style power interface with strong mechanical stability and professional integration. Unlike inline connectors, it is designed for permanent installation in systems where safety, durability, and clean wiring are important.

It offers the reliability of the XT60 family combined with the structural advantages of a panel-mount design, making it a preferred choice for drone charging ports and embedded power systems.

Package Includes

• 1 × Amass XT60IE-M.G.B Battery Connector

Product Description

The Amass XT60PW(2+1) Male Connector (XT60IPW-M.G.O) is a high-performance panel-mount PCB power connector with an integrated 2+1 pin configuration, designed for reliable power and signal transmission in drones, RC systems, robotics, UAV control boards, battery packs, and industrial electronics. Manufactured by Amass, a globally trusted connector brand, this XT60PW variant is engineered for applications where both high-current power delivery and additional signal/communication lines are required in a compact footprint.

The XT60IPW-M.G.O Male Connector features a 2 power + 1 signal pin architecture (2+1 design), allowing simultaneous transmission of power and control signals through a single connector. This reduces wiring complexity, improves system integration, and enhances reliability in advanced drone and robotics systems.

It uses precision gold-flash plated brass contacts, ensuring excellent electrical conductivity and low contact resistance. This helps minimize power loss and heat buildup during operation, making it suitable for UAV propulsion systems, ESC control circuits, and smart battery systems. The gold plating also improves corrosion resistance for long-term durability in outdoor and industrial environments.

The connector is built in a 90° PCB-mounted (right-angle) configuration, designed for direct soldering onto printed circuit boards. This allows clean PCB layout design and compact integration inside drone flight controllers, power distribution boards, and smart battery management systems.

The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, ensuring excellent insulation, mechanical strength, and thermal stability under high-load conditions. It is designed to withstand vibration, shock, and continuous electrical stress common in UAV and robotics applications.

The XT60PW(2+1) connector typically supports around 30A continuous current and up to 500V DC, depending on wiring and thermal conditions, making it suitable for medium-power drone systems and integrated electronic platforms.

Whether you're designing a smart UAV power system, building an advanced robotics controller, or developing compact embedded electronics, the Amass XT60PW(2+1) Male Connector provides a smart combination of power delivery, signal integration, and PCB-level mounting convenience.

Key Features

• Genuine Amass XT60IPW-M.G.O (XT60PW 2+1) Male Connector
• 2 power pins + 1 signal pin integrated design
• Supports combined power and communication lines
• Gold-flash plated brass contacts for high conductivity
• Low contact resistance for efficient power transfer
• PCB-mounted 90° right-angle design
• High-temperature PA (Polyamide) UL94 V-0 housing
• Strong vibration and mechanical stability
• Compact and space-saving PCB integration
• Designed for solder-type PCB installation
• Long service life with stable performance

Applications & Use Cases

• Advanced UAV and drone flight systems
• Smart battery packs with communication lines
• Power Distribution Boards (PDBs)
• ESC control and telemetry systems
• Robotics and automation systems
• Industrial embedded electronics
• RC vehicles and aircraft systems
• IoT and smart power modules
• DIY electronics and prototyping
• Battery-powered control systems

Technical Specifications

• Brand: Amass
• Model: XT60IPW-M.G.O
• Connector Type: Male
• Series: XT60PW (2+1)
• Pin Configuration: 2 power + 1 signal
• Mounting Type: PCB Through Hole (90° right-angle)
• Contact Material: Brass, gold-flash plated
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Current: 30A continuous
• Rated Voltage: 500V DC
• Mechanical Life: ~1000 mating cycles
• Operating Temperature: -20°C to 120°C
• Application Type: Power + signal PCB connector

Why Choose This Connector?

The Amass XT60PW(2+1) Male Connector is ideal for systems that require both power and signal transmission in a single compact connector. Unlike standard XT60 connectors, it reduces wiring complexity and improves system integration, especially in smart UAV and robotics platforms.

Its combination of PCB mounting, dual-function design, and Amass-grade reliability makes it a preferred choice for advanced electronic systems.

Package Includes

• 1 × Amass XT60IPW-M.G.O (XT60PW 2+1) Male Connector

Product Description

The Amass XT150 Male Connector (XT150-M.G.BL) is a premium-grade high-current single-pin DC power connector designed for demanding applications such as agriculture drones, industrial UAV systems, RC vehicles, robotics, electric mobility systems, and high-capacity lithium battery packs. Manufactured by Amass, a globally trusted connector brand, the XT150 series is engineered for ultra-low resistance, stable high-current transmission, and long-term durability in harsh operating environments.

The XT150-M.G.BL Male Connector features a precision-machined brass contact with gold flash plating, ensuring excellent conductivity and minimal contact resistance. This enables efficient power transfer with reduced voltage drop and heat generation, even under continuous high-load operation. The gold plating also improves corrosion resistance, making the connector suitable for outdoor drone and industrial applications.

Designed for high-power DC systems, the XT150 connector supports approximately 60A continuous current and up to 500V DC operation, making it suitable for UAV propulsion systems and heavy battery discharge applications. In peak conditions, it can handle significantly higher short-duration currents depending on system design and wiring.

The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and thermal stability. This rugged construction ensures safe operation under vibration, shock, and continuous electrical stress—common conditions in drones, robotics, and electric vehicles.

A key design advantage of the XT150 series is its large contact surface area (bullet-style high-power interface), which reduces resistance and improves current-carrying efficiency compared to smaller XT connectors. This makes it especially suitable for high-load battery packs, ESC connections, and power distribution systems where stability is critical.

Whether you're building a professional agricultural drone, assembling a high-capacity battery system, or designing industrial electronics, the Amass XT150 Male Connector delivers reliable performance, strong mechanical durability, and efficient power handling.

Key Features

• Genuine Amass XT150-M.G.BL Male Connector
• High-current single-pin DC power connector
• Gold flash plated brass contact for excellent conductivity
• Low contact resistance for efficient energy transfer
• Supports ~60A continuous current (application dependent)
• Rated for up to 500V DC systems
• High-temperature PA (Polyamide) UL94 V-0 flame-retardant housing
• Large contact surface for improved current flow
• Strong vibration and mechanical resistance
• Durable design for long service life
• Easy solder-type wire termination
• Reliable connection for high-power systems

Applications & Use Cases

• Agriculture drones and spraying UAVs
• Heavy-lift industrial drones (VTOL systems)
• Lithium-ion and LiPo battery packs
• Battery-to-ESC power connections
• RC cars, boats, and aircraft
• Robotics and automation systems
• Industrial power distribution systems
• Electric vehicles and mobility systems
• High-current charging systems
• DIY electronics and prototyping projects

Technical Specifications

• Brand: Amass
• Model: XT150-M.G.BL
• Connector Type: Male
• Series: XT150
• Contact Material: Brass, gold flash plated
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Current: ~60A continuous
• Rated Voltage: 500V DC
• Wire Compatibility: Up to 8 AWG
• Mechanical Life: ~1000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Solder wire connection
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT150 Male Connector is ideal for users who need a robust high-current connector with minimal power loss and strong mechanical reliability. Its large contact design ensures stable current delivery, while the rugged housing ensures long-term performance in demanding environments.

Compared to smaller XT-series connectors, the XT150 offers higher current handling capability, better thermal stability, and superior durability, making it a preferred choice for professional UAV and industrial power systems.

Package Includes

• 1 × Amass XT150 Male Connector (XT150-M.G.BL)

Product Description

The Amass XT60(2+1) Female Connector (XT60I-F.G.O) is a high-quality 3-pin hybrid DC power connector designed for advanced power and signal integration in drones, UAV systems, robotics, smart battery packs, RC vehicles, and industrial electronic applications. Manufactured by Amass, a globally trusted connector brand, this XT60(2+1) series is engineered to provide reliable high-current power delivery along with an additional signal line, enabling smarter and more efficient electronic system design.

The XT60I-F.G.O Female Connector features a 2+1 pin architecture, consisting of two main power contacts and one auxiliary signal/identification pin. This additional pin is commonly used for functions such as battery identification, communication, or system recognition in smart power systems. This makes it highly suitable for next-generation UAV and battery management applications where simple power-only connectors are no longer sufficient.

It uses precision gold-flash plated brass contacts, ensuring excellent electrical conductivity, low resistance, and stable current transfer. This helps minimize heat generation and power loss during continuous operation, making it suitable for drone propulsion systems, ESC connections, and high-capacity lithium battery setups. The gold plating also enhances corrosion resistance, ensuring long-term reliability in outdoor and industrial environments.

The connector supports a straight cable-mount design with solder-type termination, allowing secure and durable wiring for field and manufacturing use. The housing is made from high-temperature PA (Polyamide) thermoplastic with UL94 V-0 flame-retardant rating, providing strong insulation, mechanical durability, and thermal stability under demanding conditions.

The XT60(2+1) series is typically rated for around 30A continuous current and up to 500V DC operation, depending on wire gauge and system configuration. This makes it suitable for medium-power UAV systems and smart electronic platforms where both power and signal communication are required.

Whether you're designing an advanced drone system, building a smart lithium battery pack, or developing robotics with integrated power monitoring, the Amass XT60(2+1) Female Connector provides a compact and intelligent connectivity solution.

Key Features

• Genuine Amass XT60I-F.G.O Female Connector
• 2 power pins + 1 signal/communication pin (2+1 design)
• Ideal for smart battery and identification systems
• Gold-flash plated brass contacts for high conductivity
• Low contact resistance for efficient power transfer
• High-temperature PA (Polyamide) UL94 V-0 housing
• Secure friction-fit cable-mount design
• Supports power + signal integration in one connector
• Strong resistance to vibration and mechanical stress
• Easy solder-type wire termination
• Long service life with stable performance

Applications & Use Cases

• Smart UAV and drone battery systems
• Lithium battery packs with communication/ID lines
• Power Distribution Boards (PDBs)
• ESC and flight controller integration
• Robotics and automation systems
• RC cars, boats, and aircraft
• Industrial embedded electronics
• IoT and smart power systems
• Battery monitoring and management systems (BMS)
• DIY electronics and prototyping

Technical Specifications

• Brand: Amass
• Model: XT60I-F.G.O
• Connector Type: Female
• Series: XT60(2+1) / XT60I
• Pin Configuration: 2 power + 1 signal pin
• Contact Material: Brass, gold-flash plated
• Housing Material: PA (Polyamide), UL94 V-0 flame-retardant
• Rated Current: ~30A continuous
• Rated Voltage: 500V DC
• Mounting Type: Cable mount, solder termination
• Wire Compatibility: Typically 12–14 AWG
• Operating Temperature: -20°C to 120°C
• Mechanical Life: ~1000 mating cycles
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT60(2+1) Female Connector is designed for modern electronic systems that require more than just power delivery. Its additional signal pin enables smart communication between battery and device, improving system intelligence and safety.

Compared to standard XT60 connectors, it offers enhanced functionality without increasing size significantly, making it a strong choice for next-generation drones and smart power systems.

Package Includes

• 1 × Amass XT60I-F.G.O (XT60 2+1) Female Connector

Product Description

The Amass XT150 Gold Plated Male Connector – Black (XT150-M.G.B) is a premium high-current single-pole DC power connector engineered for reliable and efficient power transmission in agriculture drones, industrial UAVs, RC vehicles, electric vehicles, robotics, battery packs, and high-power electronic systems. Manufactured by Amass, a globally trusted connector brand, the XT150 series is designed to provide low-resistance electrical performance, high current handling capability, and exceptional mechanical durability for demanding applications.

The XT150-M.G.B Male Connector features a precision-machined brass contact with premium gold plating, ensuring superior electrical conductivity and minimal contact resistance. The gold-plated contact significantly reduces voltage drop and heat generation while providing excellent resistance to oxidation and corrosion, ensuring reliable performance over extended periods of use.

Designed for high-current DC power systems, the XT150 connector is rated for 60A continuous current and up to 130A peak current, depending on wire gauge and operating conditions. It also supports 500V DC systems, making it an excellent choice for professional drone power systems, battery packs, motor controllers, and industrial electronics.

One of the key advantages of the XT150 series is its large 6mm bullet contact design, which provides a significantly larger contact surface than standard connectors. This design lowers electrical resistance, improves heat dissipation, and enables efficient high-current transfer. The detachable black housing also allows users to combine multiple XT150 connectors using the integrated dovetail locking system, making it easy to build custom battery connectors for different applications.

The housing is manufactured from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing outstanding insulation, mechanical strength, and thermal stability. Its rugged construction resists vibration, impact, and continuous electrical stress, making it ideal for outdoor UAV operations and industrial environments.

Whether you're assembling a heavy-lift drone, upgrading an RC vehicle, building a high-capacity lithium battery pack, or designing industrial power systems, the Amass XT150 Gold Plated Male Connector delivers professional-grade reliability, efficient power transfer, and long-lasting performance.

Key Features

• Genuine Amass XT150-M.G.B Gold Plated Male Connector
• High-current single-pole DC power connector
• Premium gold-plated brass contact for maximum conductivity
• Low contact resistance for efficient power transfer
• Rated for 60A continuous current
• Supports 130A peak current
• Rated for 500V DC
• Large 6mm bullet contact for improved current handling
• High-temperature PA (Nylon) UL94 V-0 flame-retardant housing
• Detachable housing with dovetail locking design
• Excellent resistance to heat, vibration, and corrosion
• Easy solder-type wire termination

Applications & Use Cases

The Amass XT150 Gold Plated Male Connector is widely used in:

• Agriculture drones and spraying UAVs
• Heavy-lift commercial drones
• FPV drone battery systems
• Lithium-ion and LiPo battery packs
• Electronic Speed Controllers (ESCs)
• Brushless motor power connections
• RC cars, boats, helicopters, and aircraft
• Electric vehicles (EVs) and e-bikes
• Robotics and industrial automation
• High-current battery charging systems
• Solar energy storage systems
• DIY electronics and custom battery projects

Technical Specifications

• Brand: Amass
• Model: XT150-M.G.B
• Connector Type: Male
• Series: XT150
• Number of Poles: 1
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide/Nylon), UL94 V-0
• Rated Current: 60A Continuous
• Peak Current: 130A
• Rated Voltage: 500V DC
• Contact Resistance: ≤0.20mΩ
• Recommended Wire Size: 8 AWG
• Mechanical Life: 1000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount, solder termination
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT150 Gold Plated Male Connector is an excellent choice for engineers, drone manufacturers, robotics professionals, and RC enthusiasts who require safe, efficient, and reliable high-current power connections. Its large gold-plated contact surface minimizes power loss while maximizing current capacity, making it ideal for demanding electrical systems.

Compared to conventional bullet connectors, the XT150 series offers higher current capability, lower resistance, superior thermal performance, and a rugged flame-retardant housing, ensuring dependable operation in professional and industrial applications.

Package Includes

• 1 × Amass XT150 Gold Plated Male Connector – Black (XT150-M.G.B)

Product Description

The Amass MR60 Female Connector (MR60-F.G.Y) is a premium 3-pin high-current DC power connector designed for reliable motor-to-ESC and power connections in FPV drones, UAVs, RC aircraft, RC cars, robotics, industrial automation, and brushless motor applications. Manufactured by Amass, a globally recognized leader in connector technology, the MR60 series combines three gold-plated bullet connectors into a single insulated housing, providing a safer, cleaner, and more reliable alternative to individual bullet connectors.

The MR60-F.G.Y Female Connector features three precision-machined gold flash plated brass contacts, offering excellent electrical conductivity and ultra-low contact resistance. This minimizes power loss and heat generation while ensuring stable current delivery during continuous operation. The gold plating also provides outstanding resistance to oxidation and corrosion, extending the connector's service life even in demanding outdoor environments.

Designed specifically for 3-phase brushless motor connections, the MR60 connector eliminates wiring confusion by integrating all three motor phase wires into a single compact connector. This significantly simplifies installation, improves cable management, and reduces the possibility of incorrect wiring during assembly or maintenance.

The connector is manufactured using high-temperature PA66 (Nylon) thermoplastic with a UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and heat resistance. Its rugged housing withstands vibration, mechanical shock, and continuous electrical loading, making it ideal for high-performance drone and robotics applications.

The MR60 series is rated for 30A continuous current and up to 500V DC, depending on wire size and operating conditions. It supports 12 AWG wire and utilizes solder-type termination for secure electrical connections. With a mechanical durability of approximately 1,000 mating cycles, it delivers dependable long-term performance in both commercial and hobby-grade applications.

Whether you're assembling an FPV racing drone, building an industrial UAV, wiring a brushless motor, or upgrading an RC vehicle, the Amass MR60 Female Connector delivers professional-grade power transmission, reliable electrical performance, and exceptional durability.

Key Features

• Genuine Amass MR60-F.G.Y Female Connector
• 3-pin integrated connector for brushless motors
• Gold flash plated brass contacts for superior conductivity
• Low contact resistance for efficient power transfer
• Rated for 30A continuous current
• Supports up to 500V DC
• High-temperature PA66 (Nylon) UL94 V-0 flame-retardant housing
• Integrated housing simplifies motor wiring
• Excellent resistance to vibration, heat, and corrosion
• Supports up to 12 AWG wire
• Solder-type wire termination
• Long mechanical life of approximately 1,000 mating cycles

Applications & Use Cases

The Amass MR60 Female Connector is widely used in:

• FPV racing drones
• Commercial and industrial UAVs
• Brushless motor to ESC connections
• RC airplanes and helicopters
• RC cars and boats
• Robotics and automation systems
• Agricultural drones
• Electric skateboards and e-mobility projects
• Industrial motor controllers
• DIY electronics and prototyping
• Battery-powered motor systems
• Embedded power distribution systems

Technical Specifications

• Brand: Amass
• Model: MR60-F.G.Y
• Connector Type: Female
• Series: MR60
• Number of Pins: 3
• Contact Material: Brass, gold flash plated
• Housing Material: PA66 (Nylon), UL94 V-0 flame-retardant
• Rated Current: 30A Continuous
• Rated Voltage: 500V DC
• Wire Size: Up to 12 AWG
• Mechanical Life: 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount
• Electrical Connection: Solder termination
• Contact Plating: Gold flash

Why Choose This Connector?

The Amass MR60 Female Connector is engineered for professionals, drone builders, RC enthusiasts, and robotics developers who need a compact, high-current, and highly reliable 3-phase motor connector. Its integrated three-pin design reduces wiring complexity, improves installation speed, and provides a cleaner, more secure connection than individual bullet connectors.

Compared to conventional motor connectors, the MR60 series offers excellent conductivity, rugged construction, superior vibration resistance, and long-lasting durability, making it an ideal solution for demanding drone, robotics, and industrial applications.

Package Includes

• 1 × Amass MR60 Female Connector (MR60-F.G.Y)

Product Description

The Amass XT150 Male Connector (XT150-M.G.R) is a premium high-current single-pole DC power connector designed for demanding applications such as agriculture drones, industrial UAVs, RC aircraft, RC cars, robotics, electric vehicles, battery packs, and industrial power systems. Manufactured by Amass, a globally recognized leader in connector technology, the XT150 series is engineered to deliver low-resistance power transmission, exceptional current-carrying capability, and long-term reliability in high-power electrical applications.

The XT150-M.G.R Male Connector features a precision-machined brass contact with premium gold plating, ensuring excellent electrical conductivity and minimal contact resistance. This results in reduced voltage drop, lower heat generation, and efficient energy transfer even during continuous high-current operation. The gold-plated contact also provides excellent resistance against corrosion and oxidation, ensuring dependable performance over extended periods of use.

Designed for high-current DC power systems, the XT150 connector is rated for 60A continuous current and can safely handle up to 130A peak current, depending on wire size and operating conditions. It supports 500V DC systems, making it an excellent choice for professional UAV power systems, high-capacity lithium battery packs, motor controllers, and industrial electronics.

One of the standout features of the XT150 series is its large 6mm spring-loaded bullet contact, which provides a significantly larger contact surface than conventional connectors. This design improves current flow, minimizes resistance, and enhances heat dissipation during demanding applications. The red high-temperature nylon (PA) housing incorporates a dovetail interlocking design, allowing multiple XT150 connectors to be combined into custom multi-pole configurations for battery packs and power distribution systems.

Manufactured using UL94 V-0 flame-retardant Polyamide (PA), the housing offers outstanding insulation, mechanical strength, and resistance to vibration, shock, and elevated temperatures. With support for 8 AWG wire and approximately 1,000 mating cycles, the connector is built for professional use in harsh operating environments.

Whether you're assembling a heavy-lift drone, upgrading an RC vehicle, building a high-capacity battery pack, or designing industrial power equipment, the Amass XT150 Male Connector delivers professional-grade performance, maximum reliability, and efficient power transmission.

Key Features

• Genuine Amass XT150-M.G.R Male Connector
• High-current single-pole DC power connector
• Premium gold-plated brass contact for superior conductivity
• Large 6mm spring-loaded bullet contact
• Low contact resistance for efficient power transfer
• Rated for 60A continuous current
• Supports 130A peak current
• Rated for 500V DC
• High-temperature PA (Polyamide) UL94 V-0 flame-retardant housing
• Dovetail interlocking housing for custom multi-pin configurations
• Excellent resistance to heat, vibration, and corrosion
• Easy solder-type wire termination

Applications & Use Cases

The Amass XT150 Male Connector is widely used in:

• Agriculture drones and spraying UAVs
• Heavy-lift commercial drones
• FPV drone battery systems
• Lithium-ion and LiPo battery packs
• Electronic Speed Controllers (ESCs)
• Brushless motor power connections
• RC cars, boats, helicopters, and aircraft
• Electric vehicles (EVs) and e-bikes
• Robotics and industrial automation
• High-current battery charging systems
• Solar energy storage systems
• DIY electronics and custom battery projects

Technical Specifications

• Brand: Amass
• Model: XT150-M.G.R
• Connector Type: Male
• Series: XT150
• Number of Poles: 1
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 60A Continuous
• Peak Current: 130A
• Rated Voltage: 500V DC
• Contact Resistance: ≤0.20mΩ
• Recommended Wire Size: 8 AWG
• Mechanical Life: 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount, solder termination
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT150 Male Connector is designed for engineers, drone manufacturers, RC enthusiasts, and industrial professionals who require safe, efficient, and dependable high-current power connections. Its large gold-plated contact minimizes electrical losses while maximizing current capacity, making it ideal for demanding power systems.

Compared to conventional bullet connectors, the XT150 series provides higher current handling, superior thermal performance, rugged flame-retardant construction, and long service life, making it the preferred choice for professional drone, EV, and industrial applications.

Package Includes

• 1 × Amass XT150 Male Connector – XT150-M.G.R

Product Description

The Amass MT60 3 Pin Female Connector (MT60-F.G.Y) is a premium 3-pole high-current motor and power connector designed for secure and efficient electrical connections in FPV drones, multirotor UAVs, RC aircraft, robotics, brushless motor systems, and industrial electronic applications. Manufactured by Amass, a globally trusted leader in connector technology, the MT60 series combines three gold-plated bullet connectors into a single compact housing, providing a reliable, organized, and vibration-resistant solution for 3-phase brushless motor connections.

The MT60-F.G.Y Female Connector features three precision-machined 3.5mm gold flash plated brass contacts, delivering excellent electrical conductivity and low contact resistance. This minimizes voltage drop and heat generation while ensuring stable current transfer during continuous operation. The gold-plated contacts also provide excellent resistance against oxidation and corrosion, ensuring dependable long-term performance in demanding outdoor and industrial environments.

Designed specifically for brushless motor-to-ESC connections, the MT60 connector simplifies wiring by integrating all three motor phase wires into a single insulated connector. This reduces installation time, improves cable management, prevents incorrect wiring, and enhances overall system reliability. Its compact design makes it particularly suitable for multirotor drones, FPV racing drones, electric aircraft, and robotic systems where space is limited.

The connector housing is manufactured from high-temperature PA66 (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and heat resistance. Its rugged construction resists vibration, mechanical shock, and continuous electrical loading, making it ideal for high-performance drone propulsion systems and industrial automation equipment.

The MT60 series is rated for 30A continuous current and 500V DC, depending on wire size and operating conditions. It supports 12 AWG wire and features solder-type wire termination for secure electrical connections. With a mechanical durability of approximately 1,000 mating cycles, it delivers reliable long-term performance in both professional and hobby-grade applications.

Whether you're building a racing drone, assembling a UAV propulsion system, designing a robotic platform, or upgrading an RC aircraft, the Amass MT60 Female Connector offers professional-grade reliability, excellent electrical efficiency, and simplified 3-phase motor connectivity.

Key Features

• Genuine Amass MT60-F.G.Y Female Connector
• 3-pin integrated connector for brushless motors
• Three 3.5mm gold flash plated brass contacts
• Low contact resistance for efficient power transfer
• Rated for 30A continuous current
• Supports 500V DC operation
• High-temperature PA66 (Nylon) UL94 V-0 flame-retardant housing
• Compact design for clean cable management
• Strong vibration and shock resistance
• Supports up to 12 AWG wire
• Solder-type wire termination
• Approximately 1,000 mating cycles for long service life

Applications & Use Cases

The Amass MT60 Female Connector is widely used in:

• FPV racing drones
• Commercial and industrial UAVs
• Brushless motor to ESC connections
• Multirotor drone propulsion systems
• RC airplanes and helicopters
• RC boats and cars
• Robotics and automation systems
• Agricultural drones
• Industrial motor controllers
• DIY electronics and prototyping
• Electric mobility projects
• Battery-powered motor systems

Technical Specifications

• Brand: Amass
• Model: MT60-F.G.Y
• Connector Type: Female
• Series: MT60
• Number of Pins: 3
• Connector Size: 3.5mm bullet contacts
• Contact Material: Brass, gold flash plated
• Housing Material: PA66 (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 30A Continuous
• Rated Voltage: 500V DC
• Wire Size: Up to 12 AWG
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount
• Electrical Connection: Solder termination

Why Choose This Connector?

The Amass MT60 Female Connector is engineered for drone builders, RC enthusiasts, robotics developers, and industrial professionals who require a compact, reliable, and high-performance 3-phase connector. Its integrated three-pin design simplifies wiring, reduces clutter, and provides a more secure and organized connection than individual bullet connectors.

Compared to conventional motor connectors, the MT60 series offers excellent conductivity, rugged flame-retardant construction, superior vibration resistance, and long-lasting durability, making it an ideal choice for professional drone, robotics, and industrial applications.

Package Includes

• 1 × Amass MT60 3 Pin Female Connector (MT60-F.G.Y)

Product Description

The Amass AS120(2+4) Female Connector (AS120(2+4)-F.G.Y+) is a premium high-current anti-spark battery connector designed for advanced power systems that require both high-current power delivery and auxiliary signal communication. Manufactured by Amass, a globally recognized leader in connector technology, this connector is widely used in agriculture drones, industrial UAVs, electric vehicles, robotics, battery management systems (BMS), and high-performance RC applications.

The AS120(2+4)-F.G.Y+ Female Connector features a 2+4 pin configuration, consisting of two high-current power contacts and four auxiliary signal pins. This integrated design allows simultaneous transmission of power and communication signals through a single connector, significantly reducing wiring complexity while improving system reliability. It is particularly suitable for smart battery systems where power, battery identification, telemetry, and communication signals must be transferred together.

The connector incorporates anti-spark technology, which helps suppress inrush current when connecting high-voltage lithium battery packs. This minimizes connector arcing, protects sensitive electronics such as ESCs and flight controllers, and extends connector life by reducing contact wear. It is an excellent solution for high-capacity LiPo batteries used in commercial UAVs and industrial equipment.

Built with gold-plated brass contacts, the AS120 connector offers excellent electrical conductivity, ultra-low contact resistance, and efficient current transfer. The premium contact plating also provides superior resistance to oxidation and corrosion, ensuring reliable performance even after repeated connection cycles.

The housing is manufactured from high-temperature Nylon (PA66) with a UL94 V-0 flame-retardant rating, providing outstanding insulation, mechanical strength, and heat resistance. Its rugged construction withstands vibration, impact, and harsh operating environments, making it ideal for outdoor drone operations and industrial automation systems.

The AS120(2+4) series supports 60A continuous current, up to 120A peak current, and 500V DC operation, depending on wire size and operating conditions. It is designed for 10 AWG cable and features solder-type termination for secure, long-lasting electrical connections.

Whether you're building an agricultural spraying drone, integrating a smart battery system, developing industrial robotics, or designing high-current embedded electronics, the Amass AS120(2+4) Female Connector provides professional-grade performance, safety, and reliability.

Key Features

• Genuine Amass AS120(2+4)-F.G.Y+ Female Connector
• High-current anti-spark battery connector
• 2 power pins + 4 auxiliary signal pins
• Integrated power and communication interface
• Gold-plated brass contacts for superior conductivity
• Anti-spark design protects electronics during battery connection
• Rated for 60A continuous current
• Supports 120A peak current
• Rated for 500V DC
• High-temperature PA66 (Nylon) UL94 V-0 flame-retardant housing
• Supports 10 AWG wire
• Solder-type wire termination
• Excellent resistance to vibration, heat, and corrosion

Applications & Use Cases

The Amass AS120(2+4) Female Connector is widely used in:

• Agricultural spraying drones
• Heavy-lift commercial UAVs
• Smart lithium battery packs
• Battery Management Systems (BMS)
• Electronic Speed Controllers (ESCs)
• Industrial robotics
• Electric vehicles (EVs)
• Autonomous mobile robots (AMRs)
• High-current battery charging systems
• Industrial automation equipment
• RC aircraft and helicopters
• Advanced DIY electronics projects

Technical Specifications

• Brand: Amass
• Model: AS120(2+4)-F.G.Y+
• Connector Type: Female
• Series: AS120 (2+4)
• Pin Configuration: 2 Power + 4 Signal Pins
• Contact Material: Gold-plated brass
• Housing Material: PA66 (Nylon), UL94 V-0 flame-retardant
• Rated Current: 60A Continuous
• Peak Current: 120A
• Rated Voltage: 500V DC
• Recommended Wire Size: 10 AWG
• Contact Resistance: ≤0.4mΩ
• Mechanical Life: 100 mating cycles
• Operating Temperature: -20°C to 120°C
• Protection Rating: IP40
• Mounting Type: Cable mount, solder termination

Why Choose This Connector?

The Amass AS120(2+4) Female Connector is engineered for professional users who require a high-current connector with integrated signal communication and anti-spark protection. Its innovative 2+4 pin architecture simplifies wiring by combining power and signal transmission into one compact connector, while the anti-spark design enhances safety and protects valuable electronic components.

Compared to conventional high-current connectors, the AS120(2+4) offers greater functionality, safer battery connections, superior conductivity, and rugged construction, making it an ideal choice for commercial drones, industrial automation, electric vehicles, and smart battery systems.

Package Includes

• 1 × Amass AS120(2+4) Female Connector (AS120(2+4)-F.G.Y+)

Product Description

The Amass AS120(2+4) Male Connector (AS120(2+4)-M.G.Y+) is a premium high-current anti-spark battery connector engineered for advanced electrical systems that require high-current power transmission along with integrated signal communication. Manufactured by Amass, a globally recognized leader in connector technology, this connector is widely used in agriculture drones, industrial UAVs, electric vehicles, robotics, battery management systems (BMS), and high-performance RC applications.

The AS120(2+4)-M.G.Y+ Male Connector features a 2+4 pin configuration, consisting of two high-current power contacts and four auxiliary signal pins. This integrated design allows power delivery and signal communication to be transmitted through a single connector, reducing wiring complexity while improving system reliability. It is particularly suitable for smart battery systems that require battery identification, telemetry, communication, and monitoring functions in addition to high-current power delivery.

The connector incorporates anti-spark technology, which significantly reduces inrush current and prevents sparking when connecting high-voltage lithium battery packs. This protects sensitive electronics such as ESCs, flight controllers, and battery management systems while extending connector lifespan by minimizing contact wear. The anti-spark feature makes it especially valuable in large UAVs, commercial drones, and industrial power systems.

Constructed with gold-plated brass contacts, the AS120 connector delivers excellent electrical conductivity, ultra-low contact resistance, and efficient power transfer. The premium gold plating provides excellent resistance to corrosion and oxidation, ensuring consistent electrical performance even after repeated mating cycles.

The housing is manufactured from high-temperature PA66 (Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and heat resistance. Its rugged construction withstands vibration, mechanical shock, and demanding outdoor environments, making it ideal for commercial drones, robotics, and industrial automation equipment.

The AS120(2+4) series supports 60A continuous current, up to 120A peak current, and 500V DC operation, depending on wire size and application conditions. It is designed for 10 AWG cable and features solder-type wire termination for secure, long-lasting electrical connections.

Whether you're assembling an agricultural spraying drone, integrating a smart lithium battery system, building an industrial robot, or developing high-current embedded electronics, the Amass AS120(2+4) Male Connector delivers professional-grade safety, reliability, and electrical performance.

Key Features

• Genuine Amass AS120(2+4)-M.G.Y+ Male Connector
• High-current anti-spark battery connector
• 2 power pins + 4 auxiliary signal pins
• Integrated power and communication interface
• Gold-plated brass contacts for superior conductivity
• Anti-spark design protects electronics during battery connection
• Rated for 60A continuous current
• Supports 120A peak current
• Rated for 500V DC
• High-temperature PA66 (Nylon) UL94 V-0 flame-retardant housing
• Supports 10 AWG wire
• Solder-type wire termination
• Excellent resistance to vibration, heat, and corrosion

Applications & Use Cases

The Amass AS120(2+4) Male Connector is widely used in:

• Agricultural spraying drones
• Heavy-lift commercial UAVs
• Smart lithium battery packs
• Battery Management Systems (BMS)
• Electronic Speed Controllers (ESCs)
• Industrial robotics
• Electric vehicles (EVs)
• Autonomous mobile robots (AMRs)
• High-current battery charging systems
• Industrial automation equipment
• RC aircraft and helicopters
• Advanced DIY electronics projects

Technical Specifications

• Brand: Amass
• Model: AS120(2+4)-M.G.Y+
• Connector Type: Male
• Series: AS120 (2+4)
• Pin Configuration: 2 Power + 4 Signal Pins
• Contact Material: Gold-plated brass
• Housing Material: PA66 (Nylon), UL94 V-0 flame-retardant
• Rated Current: 60A Continuous
• Peak Current: 120A
• Rated Voltage: 500V DC
• Recommended Wire Size: 10 AWG
• Contact Resistance: ≤0.4mΩ
• Mechanical Life: 100 mating cycles
• Operating Temperature: -20°C to 120°C
• Protection Rating: IP40
• Mounting Type: Cable mount, solder termination

Why Choose This Connector?

The Amass AS120(2+4) Male Connector is engineered for professionals who require a high-current connector with integrated signal communication and anti-spark protection. Its innovative 2+4 pin configuration simplifies wiring by combining power and communication into a single connector, while the anti-spark design protects valuable electronic equipment during battery connection.

Compared to conventional high-current connectors, the AS120(2+4) offers greater functionality, safer battery connections, superior conductivity, and rugged industrial-grade construction, making it an excellent choice for commercial drones, robotics, electric vehicles, and advanced battery systems.

Package Includes

• 1 × Amass AS120(2+4) Male Connector (AS120(2+4)-M.G.Y+)

Product Description

The Amass XT120(2+4) Gold Plated Yellow Female Connector (XT120(2+4)-F.G.Y+) is a premium high-current hybrid power connector engineered for applications that require both high-current power transmission and multiple signal connections in a single compact interface. Manufactured by Amass, a globally trusted connector manufacturer, this XT120 series connector is ideal for agriculture drones, industrial UAVs, electric vehicles, robotics, smart battery systems, RC aircraft, and industrial automation equipment.

The XT120(2+4)-F.G.Y+ Female Connector features a 2+4 pin configuration, comprising two high-current power contacts and four auxiliary signal pins. This innovative design enables simultaneous transmission of power and communication signals through one connector, reducing wiring complexity while improving installation efficiency and system reliability. It is particularly suitable for smart battery systems, battery management systems (BMS), telemetry, and advanced drone electronics.

The connector is equipped with precision gold-plated brass contacts that provide excellent electrical conductivity, ultra-low contact resistance, and efficient power transfer. Gold plating also offers excellent resistance to oxidation and corrosion, ensuring stable performance and long service life even in demanding outdoor and industrial environments.

Built for high-current DC applications, the XT120(2+4) connector supports 60A continuous current through its main power contacts, with a maximum voltage rating of 500V DC. The four auxiliary signal pins are designed to carry low-current communication and control signals, making the connector ideal for intelligent battery and power management systems.

The housing is manufactured from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical durability, and heat resistance. Its rugged construction withstands vibration, impact, and continuous electrical loading, making it suitable for harsh operating environments commonly encountered in drones and industrial equipment.

Whether you're building a commercial UAV, integrating a smart lithium battery pack, designing industrial robotics, or developing advanced electronic systems, the Amass XT120(2+4) Gold Plated Yellow Female Connector delivers professional-grade reliability, efficient power transmission, and simplified wiring.

Key Features

• Genuine Amass XT120(2+4)-F.G.Y+ Female Connector
• High-current hybrid power and signal connector
• 2 power pins + 4 auxiliary signal pins
• Gold-plated brass contacts for superior conductivity
• Low contact resistance for efficient energy transfer
• Rated for 60A continuous current
• Supports 500V DC operation
• Four dedicated signal pins for communication and monitoring
• High-temperature PA (Nylon) UL94 V-0 flame-retardant housing
• Excellent resistance to heat, vibration, and corrosion
• Solder-type wire termination
• Compact and durable construction

Applications & Use Cases

The Amass XT120(2+4) Female Connector is widely used in:

• Agricultural spraying drones
• Heavy-lift commercial UAVs
• Smart lithium battery packs
• Battery Management Systems (BMS)
• Electric vehicles (EVs)
• Robotics and industrial automation
• RC aircraft and helicopters
• High-current battery charging systems
• Industrial power distribution equipment
• Telemetry-enabled battery systems
• DIY electronics and custom power projects
• Embedded electronic systems

Technical Specifications

• Brand: Amass
• Model: XT120(2+4)-F.G.Y+
• Connector Type: Female
• Series: XT120 (2+4)
• Pin Configuration: 2 Power + 4 Signal Pins
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 60A Continuous
• Rated Voltage: 500V DC
• Signal Pin Rating: 1A per signal pin
• Recommended Wire Size: 8–12 AWG
• Mechanical Life: Approximately 100 mating cycles
• Operating Temperature: -20°C to 120°C
• Protection Rating: IP40
• Mounting Type: Cable mount, solder termination

Why Choose This Connector?

The Amass XT120(2+4) Gold Plated Yellow Female Connector is designed for professionals who require high-current power transmission together with integrated signal connectivity. Its 2+4 pin architecture reduces wiring complexity while enabling advanced battery monitoring, telemetry, and communication functions within a single compact connector.

Compared to conventional power connectors, the XT120(2+4) provides greater functionality, excellent electrical efficiency, rugged construction, and reliable long-term performance, making it an ideal choice for professional UAVs, robotics, electric mobility, and industrial electronic systems.

Package Includes

• 1 × Amass XT120(2+4) Gold Plated Yellow Female Connector (XT120(2+4)-F.G.Y+)

Product Description

The Amass XT120(2+4) Gold Plated Yellow Male Connector (XT120(2+4)-M.G.Y+) is a premium high-current hybrid power connector designed for applications that require both high-current power transmission and integrated signal communication in a single compact connector. Manufactured by Amass, a globally trusted leader in connector technology, this connector is widely used in agriculture drones, industrial UAVs, electric vehicles, robotics, battery management systems (BMS), RC aircraft, and industrial automation equipment.

The XT120(2+4)-M.G.Y+ Male Connector features a 2+4 pin configuration, consisting of two high-current power contacts and four auxiliary signal pins. This hybrid design allows simultaneous transmission of electrical power and communication signals through a single connector, reducing wiring complexity while improving installation efficiency and overall system reliability. It is particularly suitable for smart battery systems, telemetry-enabled UAVs, and applications requiring battery identification and communication.

The connector is equipped with precision gold-plated brass contacts, providing excellent electrical conductivity, ultra-low contact resistance, and efficient power transfer. The premium gold plating minimizes voltage drop and heat generation while offering outstanding resistance to corrosion and oxidation, ensuring stable long-term performance even in demanding environments.

Designed for high-current DC applications, the XT120(2+4) connector is rated for 60A continuous current, with 120A peak current capability, and supports 500V DC operation. The four auxiliary signal pins are designed for low-current communication and monitoring functions, making the connector ideal for intelligent battery systems and advanced electronic control applications.

The housing is manufactured from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, mechanical strength, and thermal stability. Its rugged construction resists vibration, mechanical shock, and continuous electrical loading, making it well suited for harsh outdoor environments and industrial applications. With solder-type wire termination and support for 8–12 AWG wire, the connector ensures secure, durable electrical connections.

Whether you're building a commercial UAV, integrating a smart battery pack, designing industrial robotics, or developing high-current electronic systems, the Amass XT120(2+4) Gold Plated Yellow Male Connector delivers professional-grade reliability, efficient power transmission, and simplified system integration.

Key Features

• Genuine Amass XT120(2+4)-M.G.Y+ Male Connector
• High-current hybrid power and signal connector
• 2 power pins + 4 auxiliary signal pins
• Premium gold-plated brass contacts for excellent conductivity
• Low contact resistance for efficient power transfer
• Rated for 60A continuous current
• Supports 120A peak current
• Rated for 500V DC
• High-temperature PA (Nylon) UL94 V-0 flame-retardant housing
• Excellent resistance to heat, vibration, and corrosion
• Supports 8–12 AWG wire
• Solder-type wire termination

Applications & Use Cases

The Amass XT120(2+4) Male Connector is widely used in:

• Agricultural spraying drones
• Heavy-lift commercial UAVs
• Smart lithium battery packs
• Battery Management Systems (BMS)
• Electric vehicles (EVs)
• Robotics and industrial automation
• RC aircraft and helicopters
• High-current battery charging systems
• Industrial power distribution equipment
• Telemetry-enabled battery systems
• DIY electronics and custom power projects
• Embedded electronic systems

Technical Specifications

• Brand: Amass
• Model: XT120(2+4)-M.G.Y+
• Connector Type: Male
• Series: XT120 (2+4)
• Pin Configuration: 2 Power + 4 Signal Pins
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 60A Continuous
• Peak Current: 120A
• Rated Voltage: 500V DC
• Signal Pin Rating: Up to 1A per pin
• Recommended Wire Size: 8–12 AWG
• Contact Resistance: ≤1.0mΩ
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Protection Rating: IP40
• Mounting Type: Cable mount, solder termination

Why Choose This Connector?

The Amass XT120(2+4) Gold Plated Yellow Male Connector is an ideal solution for professionals who need high-current power transmission combined with integrated signal communication. Its 2+4 pin architecture reduces cable clutter while enabling battery monitoring, telemetry, and communication through a single connector.

Compared to conventional power connectors, the XT120(2+4) offers higher functionality, excellent electrical efficiency, durable flame-retardant construction, and reliable long-term performance, making it an excellent choice for commercial drones, robotics, electric mobility, and industrial electronic systems.

Package Includes

• 1 × Amass XT120(2+4) Gold Plated Yellow Male Connector (XT120(2+4)-M.G.Y+)

Product Description

The Amass XT90 Female Connector with Housing (XT90H-F.G.Y) is a premium high-current DC power connector designed for reliable and efficient power transmission in agriculture drones, industrial UAVs, RC aircraft, electric vehicles, robotics, battery packs, and high-power electronic systems. Manufactured by Amass, a globally recognized leader in connector technology, the XT90H series is engineered to deliver safe, low-resistance, and high-current electrical connections for demanding applications.

The XT90H-F.G.Y Female Connector features precision-machined gold-plated brass contacts that provide excellent electrical conductivity and extremely low contact resistance. The gold plating minimizes voltage drop and heat generation while offering superior resistance to corrosion and oxidation, ensuring reliable long-term performance even in harsh operating environments.

One of the key advantages of the XT90H series is its integrated protective housing (end cap), which provides enhanced insulation, strain relief, and improved cable management. The housing protects solder joints from mechanical stress while giving the finished assembly a cleaner and more professional appearance. It also helps reduce the risk of accidental short circuits during installation and operation.

Designed for high-current DC power systems, the XT90H connector supports up to 90A continuous current (application dependent) and operates at up to 500V DC, making it suitable for high-capacity LiPo battery packs, UAV propulsion systems, ESCs, and industrial power equipment.

The connector housing is manufactured from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, heat resistance, and mechanical durability. Its rugged construction withstands vibration, impact, and continuous electrical loading, making it ideal for demanding outdoor and industrial applications.

Whether you're assembling a professional drone, building a high-capacity battery pack, upgrading an RC vehicle, or designing industrial power systems, the Amass XT90H Female Connector with Housing delivers professional-grade reliability, efficient power transfer, and long service life.

Key Features

• Genuine Amass XT90H-F.G.Y Female Connector with Housing
• High-current DC power connector with protective housing
• Premium gold-plated brass contacts for superior conductivity
• Low contact resistance for efficient power transfer
• Supports up to 90A continuous current
• Rated for 500V DC
• Integrated housing provides strain relief and cable protection
• High-temperature PA (Nylon) UL94 V-0 flame-retardant housing
• Excellent resistance to heat, vibration, and corrosion
• Supports 10 AWG wire
• Solder-type wire termination
• Durable construction with long mechanical life

Applications & Use Cases

The Amass XT90H Female Connector is widely used in:

• Agriculture drones and spraying UAVs
• Heavy-lift commercial drones
• FPV drone battery systems
• Lithium-ion and LiPo battery packs
• Electronic Speed Controllers (ESCs)
• RC cars, boats, helicopters, and aircraft
• Electric vehicles (EVs) and e-bikes
• Robotics and industrial automation
• Portable power stations
• Solar energy storage systems
• High-current charging systems
• DIY electronics and battery projects

Technical Specifications

• Brand: Amass
• Model: XT90H-F.G.Y
• Connector Type: Female
• Series: XT90H
• Number of Pins: 2
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: Up to 90A continuous (application dependent)
• Rated Voltage: 500V DC
• Recommended Wire Size: 10 AWG
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount
• Electrical Connection: Solder termination
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT90H Female Connector with Housing is ideal for professionals and hobbyists who require a safe, high-current, and highly reliable power connector. Its integrated housing protects solder joints, improves cable management, and enhances connector durability, while the gold-plated contacts ensure maximum electrical efficiency and dependable long-term performance.

Compared to standard XT90 connectors, the XT90H version offers better cable protection, improved mechanical strength, cleaner installation, and enhanced reliability, making it an excellent choice for professional drones, robotics, electric vehicles, and industrial power systems.

Package Includes

• 1 × Amass XT90 Female Connector with Housing (XT90H-F.G.Y)

Product Description

The Amass XT90E-M Gold Plated Black Connector (XT90E-M.G.B) is a premium panel-mount high-current DC power connector designed for secure and efficient power transmission in agriculture drones, industrial UAVs, robotics, RC aircraft, electric vehicles, battery packs, charging stations, and industrial electronic systems. Manufactured by Amass, a globally trusted connector manufacturer, the XT90E series combines the proven XT90 electrical interface with a flange-mounted housing, making it ideal for fixed installations where a robust panel-mounted power connection is required.

The XT90E-M.G.B Male Connector features precision gold-plated copper alloy contacts that provide excellent electrical conductivity, ultra-low contact resistance, and efficient current transfer. The gold plating minimizes voltage drop and heat generation while offering outstanding resistance to oxidation and corrosion, ensuring dependable long-term performance even in demanding operating environments.

Designed for panel-mounted power distribution systems, the XT90E-M connector incorporates a two-hole flange mounting design, allowing it to be securely fixed onto enclosures, charging stations, battery cases, and equipment panels. This provides a stable connection while simplifying installation and maintenance in professional electronic systems.

The connector supports 30A continuous current and operates at up to 500V DC, making it suitable for medium- to high-power electrical systems. It accommodates 8–12 AWG wires through solder-type termination, ensuring strong electrical and mechanical connections for high-current applications.

The housing is manufactured from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, heat resistance, and mechanical durability. Its rugged construction withstands vibration, impact, and continuous electrical loading, making it suitable for outdoor drone operations and industrial automation systems.

Whether you're designing a professional UAV, building a battery charging station, integrating an industrial power distribution system, or developing a robotics platform, the Amass XT90E-M Gold Plated Black Connector delivers reliable power transmission, secure panel mounting, and long-lasting performance.

Key Features

• Genuine Amass XT90E-M.G.B Male Connector
• Panel-mount high-current DC power connector
• Premium gold-plated copper alloy contacts
• Low contact resistance for efficient power transfer
• Rated for 30A continuous current
• Supports 500V DC operation
• Two-hole flange design for secure panel mounting
• High-temperature PA (Nylon) UL94 V-0 flame-retardant housing
• Excellent resistance to heat, vibration, and corrosion
• Supports 8–12 AWG wire
• Solder-type wire termination
• Long mechanical life with reliable performance

Applications & Use Cases

The Amass XT90E-M Male Connector is widely used in:

• Agriculture drones and industrial UAVs
• Battery charging stations
• Lithium-ion and LiPo battery packs
• Electric vehicles (EVs) and e-bikes
• Robotics and automation systems
• RC aircraft, helicopters, boats, and cars
• Industrial power distribution panels
• Portable power stations
• Solar energy storage systems
• Embedded electronic equipment
• DIY electronics and custom battery projects
• High-current charging systems

Technical Specifications

• Brand: Amass
• Model: XT90E-M.G.B
• Connector Type: Male
• Series: XT90E
• Number of Pins: 2
• Contact Material: Gold-plated copper alloy
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 30A Continuous
• Rated Voltage: 500V DC
• Recommended Wire Size: 8–12 AWG
• Contact Resistance: ≤0.4mΩ
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Panel mount (2-hole flange)
• Electrical Connection: Solder termination
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT90E-M Gold Plated Black Connector is an excellent choice for engineers, drone manufacturers, and industrial professionals who require a secure panel-mounted high-current connector with dependable electrical performance. Its flange-mounted design provides stable installation, while the gold-plated contacts ensure efficient power transfer and long service life.

Compared to standard cable-mounted XT90 connectors, the XT90E series offers easier panel integration, improved mechanical stability, and a cleaner installation, making it ideal for battery enclosures, charging systems, UAVs, robotics, and industrial electronic equipment.

Package Includes

• 1 × Amass XT90E-M Gold Plated Black Connector (XT90E-M.G.B)

Product Description

The Amass XT90PB30 Male Connector (XT90PB-M.G.Y) is a premium PCB-mounted high-current DC power connector designed for reliable power transmission in agriculture drones, industrial UAVs, robotics, battery management systems, RC vehicles, electric mobility systems, and industrial electronic equipment. Manufactured by Amass, a globally trusted connector brand, the XT90PB series combines the proven XT90 interface with a vertical PCB mounting design, making it ideal for applications requiring a secure board-mounted high-power connection.

The XT90PB-M.G.Y Male Connector features precision gold-plated brass contacts, providing excellent electrical conductivity, low contact resistance, and efficient power transfer. The premium gold plating minimizes voltage drop and heat generation while offering superior resistance to oxidation and corrosion, ensuring dependable long-term performance in demanding environments.

Designed for PCB-mounted power systems, the XT90PB30 connector uses a through-hole vertical (THT) mounting configuration, allowing direct installation onto printed circuit boards. This design provides a strong mechanical connection, simplifies PCB assembly, and is ideal for power distribution boards, charging stations, battery management systems, and embedded electronic equipment.

The connector supports 40A continuous current and operates at up to 500V DC, making it suitable for medium- to high-power applications such as drone power systems, industrial automation, and lithium battery integration. Its compact yet rugged construction provides excellent electrical efficiency while maintaining reliable performance under continuous operation.

The housing is manufactured from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, heat resistance, and mechanical durability. Its robust construction resists vibration, mechanical shock, and continuous electrical loading, making it suitable for demanding outdoor and industrial environments.

Whether you're designing a professional UAV, developing a battery charging system, building a power distribution board, or integrating industrial automation equipment, the Amass XT90PB30 Male Connector delivers professional-grade reliability, efficient power transfer, and secure PCB mounting.

Key Features

• Genuine Amass XT90PB-M.G.Y Male Connector
• PCB-mounted high-current DC power connector
• Vertical through-hole (THT) PCB mounting
• Premium gold-plated brass contacts
• Low contact resistance for efficient power transfer
• Rated for 40A continuous current
• Supports 500V DC operation
• High-temperature PA (Polyamide/Nylon) UL94 V-0 flame-retardant housing
• Excellent resistance to heat, vibration, and corrosion
• Secure PCB mounting for reliable installation
• Long mechanical life of approximately 1,000 mating cycles
• Compact and durable construction

Applications & Use Cases

The Amass XT90PB30 Male Connector is widely used in:

• Agriculture drones and industrial UAVs
• Battery Management Systems (BMS)
• Power Distribution Boards (PDBs)
• Lithium-ion and LiPo battery systems
• Electric vehicles (EVs) and e-bikes
• Robotics and automation systems
• Industrial power supplies
• Battery charging stations
• Embedded electronic equipment
• RC aircraft, boats, cars, and helicopters
• DIY electronics and custom PCB projects
• High-current power distribution systems

Technical Specifications

• Brand: Amass
• Model: XT90PB-M.G.Y
• Connector Type: Male
• Series: XT90PB30
• Number of Pins: 2
• Mounting Type: PCB Through-Hole (Vertical/THT)
• Contact Material: Brass, gold flash plated
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 40A Continuous
• Rated Voltage: 500V DC
• Contact Resistance: ≤0.4mΩ
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT90PB30 Male Connector is an excellent choice for engineers, drone manufacturers, and electronics professionals who require a compact, PCB-mounted high-current connector with dependable electrical performance. Its vertical PCB mounting simplifies board integration, while the gold-plated contacts ensure efficient power transfer and long service life.

Compared to conventional cable-mounted XT90 connectors, the XT90PB series offers cleaner PCB integration, improved mechanical stability, and simplified assembly, making it an ideal solution for battery management systems, power distribution boards, industrial electronics, and professional UAV applications.

Package Includes

• 1 × Amass XT90PB30 Male Connector (XT90PB-M.G.Y)

Product Description

The Amass XT90PB30 Female Connector (XT90PB-F.G.Y) is a premium PCB-mounted high-current DC power connector designed for reliable and efficient power transmission in agriculture drones, industrial UAVs, robotics, battery management systems, RC aircraft, electric vehicles, power distribution boards, and industrial electronic equipment. Manufactured by Amass, a globally recognized leader in connector technology, the XT90PB series combines the proven XT90 interface with a vertical through-hole PCB mounting design, making it ideal for applications that require a secure board-mounted high-current power connection.

The XT90PB-F.G.Y Female Connector features precision gold-plated brass contacts that provide excellent electrical conductivity and ultra-low contact resistance. The gold-plated contacts reduce voltage drop and heat generation while offering outstanding resistance to corrosion and oxidation, ensuring stable electrical performance and long service life even under demanding operating conditions.

Designed for PCB-mounted power systems, the XT90PB30 connector uses a vertical through-hole (THT) mounting configuration, allowing it to be directly soldered onto printed circuit boards. This design provides excellent mechanical stability while simplifying PCB assembly for battery management systems, charging stations, power distribution boards, and embedded electronic devices.

The connector is rated for 40A continuous current and supports 500V DC operation, making it suitable for medium- to high-power electrical applications. Its compact yet rugged design ensures efficient current transfer while maintaining excellent thermal performance during continuous operation. The connector pairs with compatible XT90 male PCB or cable connectors to provide a secure, vibration-resistant electrical connection.

The housing is manufactured from high-temperature PA66 (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing outstanding insulation, heat resistance, and mechanical durability. Its robust construction withstands vibration, mechanical shock, and harsh operating environments, making it suitable for professional drone systems, industrial automation equipment, and electric mobility applications.

Whether you're designing a UAV power distribution board, integrating a lithium battery system, building an industrial control unit, or developing custom power electronics, the Amass XT90PB30 Female Connector delivers professional-grade reliability, efficient power transfer, and secure PCB integration.

Key Features

• Genuine Amass XT90PB-F.G.Y Female Connector
• PCB-mounted high-current DC power connector
• Vertical through-hole (THT) PCB mounting
• Premium gold-plated brass contacts
• Low contact resistance for efficient power transfer
• Rated for 40A continuous current
• Supports 500V DC operation
• High-temperature PA66 (Polyamide/Nylon) UL94 V-0 flame-retardant housing
• Excellent resistance to heat, vibration, and corrosion
• Secure PCB mounting for reliable installation
• Long mechanical life of approximately 1,000 mating cycles
• Compact and durable construction

Applications & Use Cases

The Amass XT90PB30 Female Connector is widely used in:

• Agriculture drones and industrial UAVs
• Battery Management Systems (BMS)
• Power Distribution Boards (PDBs)
• Lithium-ion and LiPo battery systems
• Electric vehicles (EVs) and e-bikes
• Robotics and automation systems
• Industrial power supplies
• Battery charging stations
• Embedded electronic equipment
• RC aircraft, boats, cars, and helicopters
• DIY electronics and custom PCB projects
• High-current power distribution systems

Technical Specifications

• Brand: Amass
• Model: XT90PB-F.G.Y
• Connector Type: Female
• Series: XT90PB30
• Number of Pins: 2
• Mounting Type: PCB Through-Hole (Vertical/THT)
• Contact Material: Brass, gold flash plated
• Housing Material: PA66 (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 40A Continuous
• Rated Voltage: 500V DC
• Contact Resistance: ≤0.4mΩ
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT90PB30 Female Connector is an excellent choice for engineers, drone manufacturers, and electronics professionals who require a compact, PCB-mounted high-current connector with dependable electrical performance. Its vertical PCB mounting simplifies board integration, while the gold-plated contacts ensure efficient power transfer and long-term reliability.

Compared to conventional cable-mounted XT90 connectors, the XT90PB series offers cleaner PCB integration, improved mechanical stability, and simplified assembly, making it an ideal solution for battery management systems, power distribution boards, industrial electronics, and professional UAV applications.

Package Includes

• 1 × Amass XT90PB30 Female Connector (XT90PB-F.G.Y)

Product Description

The Amass XT90PW30 Male Connector (XT90PW-M.G.Y) is a premium PCB-mounted right-angle high-current DC power connector designed for secure and efficient power transmission in agriculture drones, industrial UAVs, robotics, battery management systems, RC aircraft, electric vehicles, power distribution boards, and industrial electronic equipment. Manufactured by Amass, a globally recognized leader in connector technology, the XT90PW series combines the trusted XT90 interface with a 90-degree PCB mounting design, making it ideal for compact electronic systems where space optimization and reliable power delivery are essential.

The XT90PW-M.G.Y Male Connector features precision gold-plated brass contacts that provide excellent electrical conductivity, ultra-low contact resistance, and efficient current transfer. The premium gold plating minimizes voltage drop and heat generation while offering superior resistance to oxidation and corrosion, ensuring stable electrical performance and long service life even in demanding operating environments.

Designed for right-angle PCB mounting, the XT90PW30 connector uses a through-hole (THT) solder mounting configuration, allowing it to be securely installed directly onto printed circuit boards. The right-angle design enables horizontal cable routing, improves space utilization inside compact enclosures, and reduces mechanical stress on PCB-mounted connectors. This makes it an excellent solution for battery management systems, charging stations, UAV electronics, embedded systems, and industrial control equipment.

The connector is rated for 30A continuous current and supports up to 90A peak current with a 500V DC voltage rating, making it suitable for medium- and high-power applications. It accommodates 8–12 AWG wire and provides reliable, low-loss power transmission for battery packs, ESCs, power distribution boards, and high-performance electronic systems.

The housing is manufactured from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, providing excellent insulation, heat resistance, and mechanical durability. Its rugged construction resists vibration, impact, and continuous electrical loading, making it suitable for demanding outdoor and industrial environments. With approximately 1,000 mating cycles, the XT90PW connector offers dependable long-term performance.

Whether you're designing a UAV power distribution board, integrating a lithium battery system, building an industrial controller, or developing custom power electronics, the Amass XT90PW30 Male Connector delivers professional-grade reliability, efficient power transfer, and space-saving PCB integration.

Key Features

• Genuine Amass XT90PW-M.G.Y Male Connector
• Right-angle PCB-mounted high-current DC power connector
• Through-hole (THT) PCB mounting
• Premium gold-plated brass contacts
• Low contact resistance for efficient power transfer
• Rated for 30A continuous current
• Supports 90A peak current
• Rated for 500V DC
• High-temperature PA (Polyamide/Nylon) UL94 V-0 flame-retardant housing
• Supports 8–12 AWG wire
• Excellent resistance to heat, vibration, and corrosion
• Long mechanical life of approximately 1,000 mating cycles

Applications & Use Cases

The Amass XT90PW30 Male Connector is widely used in:

• Agriculture drones and industrial UAVs
• Battery Management Systems (BMS)
• Power Distribution Boards (PDBs)
• Lithium-ion and LiPo battery systems
• Electric vehicles (EVs) and e-bikes
• Robotics and industrial automation
• Industrial power supplies
• Battery charging stations
• Embedded electronic equipment
• RC aircraft, boats, cars, and helicopters
• DIY electronics and custom PCB projects
• High-current power distribution systems

Technical Specifications

• Brand: Amass
• Model: XT90PW-M.G.Y
• Connector Type: Male
• Series: XT90PW30
• Number of Pins: 2
• Mounting Type: Right-angle PCB Through-Hole (THT)
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 30A Continuous
• Peak Current: 90A
• Rated Voltage: 500V DC
• Recommended Wire Size: 8–12 AWG
• Contact Resistance: ≤0.4mΩ
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT90PW30 Male Connector is an excellent choice for engineers, drone manufacturers, and electronics professionals who require a compact right-angle PCB-mounted high-current connector with dependable electrical performance. Its space-saving 90-degree design simplifies PCB layouts while the gold-plated contacts ensure efficient power transfer and long-term reliability.

Compared to standard cable-mounted XT90 connectors, the XT90PW series offers cleaner PCB integration, optimized cable routing, improved mechanical stability, and simplified assembly, making it an ideal solution for battery management systems, industrial electronics, robotics, and professional UAV applications.

Package Includes

• 1 × Amass XT90PW30 Male Connector (XT90PW-M.G.Y)

Product Description

The Amass XT90S Anti Spark Connector with Housing – Female (XT90S-F.G.Y) is a premium high-current anti-spark DC power connector engineered for safe and reliable power transmission in agriculture drones, industrial UAVs, electric vehicles, robotics, RC aircraft, battery packs, portable power stations, and high-power electronic systems. Manufactured by Amass, a globally trusted leader in connector technology, the XT90S series enhances the standard XT90 design by incorporating a built-in anti-spark resistor, eliminating the large inrush spark that occurs when connecting high-voltage battery packs.

The XT90S-F.G.Y Female Connector features high-quality gold-plated brass spring contacts that provide excellent electrical conductivity, low contact resistance, and efficient power transfer. The gold plating minimizes voltage drop and heat generation while offering outstanding resistance to oxidation and corrosion, ensuring stable electrical performance and long service life even in demanding operating environments.

One of the standout features of the XT90S series is its integrated anti-spark technology, which suppresses the initial inrush current generated when connecting high-capacity lithium batteries. This protects sensitive electronic components such as ESCs, flight controllers, and battery management systems while reducing connector wear and extending service life. Unlike external anti-spark modules, the XT90S integrates this functionality directly into the connector, resulting in a cleaner, more reliable installation.

The connector includes an integrated protective housing (solder cover) that provides improved insulation, strain relief, and protection for solder joints. This housing also enhances cable management while reducing the risk of accidental short circuits during installation and operation. The XT90S Female Connector is fully compatible with standard XT90 male connectors, making upgrades simple without changing the entire power system.

Constructed from high-temperature Nylon (PA) with a UL94 V-0 flame-retardant rating, the housing offers excellent mechanical strength, thermal stability, and resistance to vibration and impact. The connector supports up to 90A continuous current, operates at 500V DC, and accepts up to 8 AWG wire, making it ideal for high-current power applications.

Whether you're assembling a professional UAV, building a high-capacity battery pack, upgrading an electric vehicle, or designing industrial power systems, the Amass XT90S Anti Spark Female Connector with Housing delivers professional-grade safety, reliability, and efficient power transmission.

Key Features

• Genuine Amass XT90S-F.G.Y Female Connector with Housing
• Built-in anti-spark technology for safe battery connections
• High-current DC power connector
• Premium gold-plated brass spring contacts
• Low contact resistance for efficient power transfer
• Supports 90A+ continuous current
• Rated for 500V DC
• Integrated housing provides strain relief and solder joint protection
• High-temperature Nylon (PA) UL94 V-0 flame-retardant housing
• Compatible with standard XT90 connectors
• Supports up to 8 AWG wire
• Easy solder-type wire termination

Applications & Use Cases

The Amass XT90S Female Connector is widely used in:

• Agriculture drones and spraying UAVs
• Heavy-lift commercial drones
• FPV drone battery systems
• Lithium-ion and LiPo battery packs
• Electronic Speed Controllers (ESCs)
• Electric vehicles (EVs) and e-bikes
• Robotics and industrial automation
• RC aircraft, helicopters, boats, and cars
• Portable power stations
• Solar energy storage systems
• High-current charging systems
• DIY electronics and battery projects

Technical Specifications

• Brand: Amass
• Model: XT90S-F.G.Y
• Connector Type: Female
• Series: XT90S
• Number of Pins: 2
• Contact Material: Gold-plated brass
• Housing Material: High-temperature Nylon (PA), UL94 V-0 flame-retardant
• Rated Current: 90A+ Continuous
• Rated Voltage: 500V DC
• Connector Size: 4.5 mm
• Recommended Wire Size: Up to 8 AWG
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount
• Electrical Connection: Solder termination
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT90S Anti Spark Female Connector with Housing is ideal for professionals and hobbyists who require a safe, high-current, and reliable power connector for lithium battery systems. Its integrated anti-spark circuit eliminates damaging connection sparks, protecting expensive electronics while extending connector lifespan. Combined with gold-plated contacts, a flame-retardant nylon housing, and compatibility with standard XT90 connectors, it offers a superior solution for demanding drone, EV, robotics, and industrial applications.

Package Includes

• 1 × Amass XT90S Anti Spark Connector with Housing – Female (XT90S-F.G.Y)

Product Description

The Amass XT90(2+2) Male Connector (XT90(2+2)-M.G.Y) is a premium hybrid high-current power and signal connector engineered for applications that require high-current power transmission along with integrated signal communication. Manufactured by Amass, a globally trusted leader in connector technology, this connector is ideal for agriculture drones, industrial UAVs, electric vehicles, robotics, smart battery systems, battery management systems (BMS), RC aircraft, and industrial automation equipment. It combines two high-current power contacts with two auxiliary signal pins, enabling both power and communication through a single compact connector.

The XT90(2+2)-M.G.Y Male Connector features precision gold-plated brass contacts that deliver excellent electrical conductivity, low contact resistance, and efficient power transfer. The gold-plated contacts minimize voltage drop and heat generation while providing excellent resistance to oxidation and corrosion, ensuring stable electrical performance even in demanding environments.

Designed specifically for high-power battery systems, the connector integrates two power terminals for DC power transmission and two signal terminals for battery communication, telemetry, battery identification, or BMS data transfer. This hybrid design significantly reduces wiring complexity, simplifies installation, and improves overall system reliability in advanced electronic applications.

The XT90(2+2) connector is rated for 45A continuous current on the power terminals (using 10 AWG wire) and supports up to 90A peak current, with a rated voltage of 150V DC. Each signal pin is rated for 1A, making it suitable for low-current communication functions while maintaining excellent electrical isolation between power and signal circuits.

Constructed from high-temperature PA (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, the housing offers outstanding insulation, mechanical durability, and thermal stability. The connector withstands vibration, mechanical shock, and harsh operating conditions, making it suitable for commercial drones, electric mobility systems, and industrial automation equipment. With an expected mechanical life of approximately 1,000 mating cycles, it provides dependable long-term performance.

Whether you're building a commercial UAV, integrating a smart battery pack, designing an electric vehicle power system, or developing industrial robotics, the Amass XT90(2+2) Male Connector delivers professional-grade reliability, efficient power transmission, and integrated signal connectivity.

Key Features

• Genuine Amass XT90(2+2)-M.G.Y Male Connector
• Hybrid power and signal connector
• 2 high-current power contacts + 2 signal pins
• Premium gold-plated brass contacts
• Low contact resistance for efficient power transfer
• Rated for 45A continuous current
• Supports 90A peak current
• Signal pins rated for 1A
• Rated for 150V DC
• High-temperature PA (Polyamide/Nylon) UL94 V-0 flame-retardant housing
• Supports 10 AWG wire
• Solder-type wire termination
• Excellent resistance to heat, vibration, and corrosion

Applications & Use Cases

The Amass XT90(2+2) Male Connector is widely used in:

• Agriculture drones and industrial UAVs
• Smart lithium battery packs
• Battery Management Systems (BMS)
• Electric vehicles (EVs) and e-bikes
• Robotics and industrial automation
• RC aircraft and helicopters
• Battery charging systems
• Industrial power distribution equipment
• Telemetry-enabled battery systems
• Embedded electronic systems
• DIY electronics and custom battery projects
• High-current power applications with integrated signal communication

Technical Specifications

• Brand: Amass
• Model: XT90(2+2)-M.G.Y
• Connector Type: Male
• Series: XT90 (2+2)
• Pin Configuration: 2 Power + 2 Signal Pins
• Contact Material: Gold-plated brass
• Housing Material: PA (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 45A Continuous (10 AWG)
• Peak Current: 90A
• Signal Pin Rating: 1A per pin
• Rated Voltage: 150V DC
• Contact Resistance: ≤1.2mΩ
• Insulation Resistance: ≥2000MΩ
• Recommended Wire Size: 10 AWG
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount, solder termination

Why Choose This Connector?

The Amass XT90(2+2) Male Connector is an ideal solution for professionals who require high-current power delivery together with integrated signal communication. Its 2+2 pin architecture simplifies wiring by combining power and data transmission into a single connector, reducing cable clutter while improving installation efficiency and system reliability.

Compared to standard XT90 connectors, the XT90(2+2) series offers the added advantage of integrated communication pins, making it particularly suitable for smart batteries, commercial UAVs, robotics, electric vehicles, and industrial automation systems where both power and signal connectivity are essential.

Package Includes

• 1 × Amass XT90(2+2) Male Connector – XT90(2+2)-M.G.Y

Product Description

The Amass XT90(2+2) Female Connector (XT90(2+2)-F.G.Y) is a premium hybrid high-current power and signal connector designed for applications that require both high-current power transmission and integrated signal communication. Manufactured by Amass, a globally recognized leader in connector technology, this connector is widely used in agriculture drones, industrial UAVs, electric vehicles, robotics, smart battery systems, Battery Management Systems (BMS), RC aircraft, and industrial automation equipment. The connector combines two high-current power contacts with two auxiliary signal pins, allowing both electrical power and communication signals to pass through a single compact connector.

The XT90(2+2)-F.G.Y Female Connector features precision gold-plated brass contacts that provide excellent electrical conductivity, low contact resistance, and efficient power transfer. The gold-plated contacts reduce voltage drop and heat generation while offering superior resistance to corrosion and oxidation, ensuring stable electrical performance and long service life even in demanding operating environments.

Designed for high-performance battery systems, the connector integrates two power terminals for high-current DC power and two signal terminals for battery communication, telemetry, battery identification, temperature sensing, or BMS data transfer. This hybrid design reduces wiring complexity, improves cable management, and increases overall system reliability, making it ideal for intelligent battery applications used in professional drones and industrial equipment.

The XT90(2+2) connector is rated for 45A continuous current (using 10 AWG wire) and supports up to 90A peak current, with a rated voltage of 500V DC. Each signal pin is designed for low-current communication (up to 1A), allowing reliable signal transmission while maintaining electrical isolation from the main power contacts.

Constructed from high-temperature PA66 (Polyamide/Nylon) with a UL94 V-0 flame-retardant rating, the housing provides excellent insulation, mechanical strength, and thermal stability. The rugged construction resists vibration, mechanical shock, and harsh environmental conditions, making it suitable for commercial UAVs, industrial robotics, electric mobility systems, and other demanding applications. The connector is designed for solder-type wire termination and offers approximately 1,000 mating cycles, ensuring dependable long-term performance.

Whether you're assembling a commercial UAV, integrating a smart lithium battery pack, designing an electric vehicle power system, or developing industrial automation equipment, the Amass XT90(2+2) Female Connector delivers professional-grade reliability, efficient power transmission, and integrated signal connectivity.

Key Features

• Genuine Amass XT90(2+2)-F.G.Y Female Connector
• Hybrid power and signal connector
• 2 high-current power contacts + 2 auxiliary signal pins
• Premium gold-plated brass contacts
• Low contact resistance for efficient power transfer
• Rated for 45A continuous current
• Supports 90A peak current
• Signal pins rated for 1A
• Rated for 500V DC
• High-temperature PA66 (Polyamide/Nylon) UL94 V-0 flame-retardant housing
• Supports 10 AWG wire
• Solder-type wire termination
• Excellent resistance to heat, vibration, and corrosion

Applications & Use Cases

The Amass XT90(2+2) Female Connector is widely used in:

• Agriculture drones and industrial UAVs
• Smart lithium battery packs
• Battery Management Systems (BMS)
• Electric vehicles (EVs) and e-bikes
• Robotics and industrial automation
• RC aircraft and helicopters
• Battery charging systems
• Industrial power distribution equipment
• Telemetry-enabled battery systems
• Embedded electronic systems
• DIY electronics and custom battery projects
• High-current applications with integrated signal communication

Technical Specifications

• Brand: Amass
• Model: XT90(2+2)-F.G.Y
• Connector Type: Female
• Series: XT90 (2+2)
• Pin Configuration: 2 Power + 2 Signal Pins
• Contact Material: Gold-plated brass
• Housing Material: PA66 (Polyamide/Nylon), UL94 V-0 flame-retardant
• Rated Current: 45A Continuous (10 AWG)
• Peak Current: 90A
• Signal Pin Rating: Up to 1A per pin
• Rated Voltage: 500V DC
• Recommended Wire Size: 10 AWG
• Mechanical Life: Approximately 1,000 mating cycles
• Operating Temperature: -20°C to 120°C
• Mounting Type: Cable mount
• Electrical Connection: Solder termination
• Protection Rating: IP40

Why Choose This Connector?

The Amass XT90(2+2) Female Connector is an excellent solution for professionals who require high-current power delivery combined with integrated signal communication. Its 2+2 pin architecture simplifies wiring by combining power and signal transmission into a single connector, reducing cable clutter while improving installation efficiency and system reliability.

Compared to conventional XT90 power connectors, the XT90(2+2) series provides the added advantage of integrated communication pins, making it particularly suitable for smart batteries, commercial UAVs, robotics, electric vehicles, and industrial automation systems where both power and signal connectivity are essential.

Package Includes

• 1 × Amass XT90(2+2) Female Connector – XT90(2+2)-F.G.Y
