Feetech FT995M-C001 Ultra-Torque Digital Servo – 105kg.cm Steel Gear Powerhouse

When standard servos reach their mechanical limits, the Feetech FT995M-C001 takes over. This industrial-grade digital servo is a true heavyweight, delivering a staggering peak stall torque of 105kg.cm at 8.4V. Engineered for large-scale RC platforms, heavy-lift UAVs, and advanced robotics, it provides the massive structural strength and holding power required to move significant loads with surgical precision.

Built to endure extreme mechanical stress, the FT995M-C001 features a full Steel Gear drivetrain and a reinforced Aluminium & Engineering Plastic case for optimal heat dissipation. Supported by high-precision ball bearings, this servo ensures smooth, jitter-free performance even when operating at the edge of its performance envelope.

Key Highlights:

• Extreme Torque Output: With 105kg.cm of peak torque, this is one of the most powerful servos in its class, ideal for giant-scale steering, sail winches, and robotic lifting arms.

• Full Steel Drivetrain: The high-tensile steel gears are designed to resist stripping and wear under the massive 10.5A stall currents, ensuring long-term reliability.

• High-Voltage Capability: Optimized for a 6V to 9V range, allowing for direct integration with 2S LiPo or high-output power systems for maximum speed and response.

• 180° Precision Motion: Offers a wide and accurate travel range (at 500→2500μsec) with a digital comparator system for superior centering and holding power.

• Robust Hybrid Housing: The CNC-machined aluminium center section acts as a vital heatsink, protecting the motor and electronics during high-duty cycles.

• Heavy-Duty 15T Spline: Features a reinforced 15T/7.6mm output spline to ensure a secure, slip-free connection with high-torque servo horns.

Technical Specifications

Pro-Builder Tip:

The FT995M-C001 is a power-hungry beast with a 10.5A stall current. To prevent "brownouts" or damage to your electronics, do not power this servo directly through a standard receiver bus. We highly recommend using a dedicated high-current power distribution board or a robust external BEC capable of handling 12A+ bursts.

Partsbaba Quality Commitment: All Feetech digital servos are 100% genuine and original. We provide a 14-day replacement warranty against manufacturing defects, giving you the confidence to power your most ambitious projects.
