JST Connectors

Product Description

The 3 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry is a high-quality PCB-mounted wire-to-board connector designed to provide secure and reliable electrical connections in compact electronic systems. Featuring a 2.0mm pitch, 3-pin configuration, and right-angle side-entry design, this connector is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, consumer electronics, and embedded systems.

Compatible with the JST PH 2.0mm series, this header is designed for through-hole (THT) PCB mounting, offering excellent mechanical strength and durability. The horizontal right-angle orientation allows cables to connect parallel to the PCB, making it ideal for compact enclosures and applications requiring low-profile cable routing.

The connector features high-quality copper alloy contacts with tin plating, ensuring low contact resistance, reliable conductivity, and excellent corrosion resistance. Its high-temperature thermoplastic housing provides superior electrical insulation and withstands soldering temperatures, making it suitable for both prototyping and production applications.

Whether you're building a drone flight controller, designing an embedded system, or creating custom electronic hardware, the 3 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry offers a compact, durable, and dependable wire-to-board connection solution.

Key Features

• JST PH 2.0mm compatible PCB header
• 3-pin wire-to-board connector
• 2.0mm pitch
• Through-hole (THT) PCB mounting
• Horizontal right-angle side-entry design
• Polarized connector prevents incorrect mating
• Tin-plated copper alloy contacts
• High-temperature thermoplastic housing
• Strong mechanical retention after soldering
• Compact, low-profile design
• Reliable electrical performance and easy installation

Applications & Use Cases

The 3 Pin JST PH 2.0mm Right Angle Header is commonly used in:

• Drones and UAV electronics
• Robotics and automation
• Battery Management Systems (BMS)
• IoT devices
• Sensor modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and PCB prototyping

Technical Specifications

• Connector Type: JST PH Compatible Header
• Number of Pins: 3
• Pitch: 2.0mm
• Mounting Type: Through-Hole (THT)
• Orientation: Horizontal Right Angle (Side Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 3-pin Female Housing

Why Choose This Header?

The 3 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry is an excellent choice for compact PCB designs that require side-entry cable routing. Its through-hole construction provides enhanced mechanical stability, while the polarized design ensures secure and reliable connections. Ideal for drones, robotics, and embedded electronics, it offers dependable performance in both development and production environments.

Package Includes

• 1 × 3 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry Connector

Product Description

The 3 Pin JST PH 2.0mm Housing is a high-quality wire-to-board connector housing designed for secure and reliable electrical connections in compact electronic applications. Compatible with the JST PH 2.0mm series, this 3-pin housing is ideal for use in drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, consumer electronics, and DIY electronics projects.

Designed to accommodate 3 crimp terminals (sold separately), the housing provides a secure, polarized connection that prevents incorrect mating and ensures stable electrical performance. Its compact design makes it suitable for high-density wiring applications where space is limited while maintaining excellent connection reliability.

Manufactured from high-quality PA66 (Nylon) thermoplastic, the housing offers excellent mechanical strength, electrical insulation, and resistance to heat and wear. The locking design securely mates with compatible JST PH 2.0mm 3-pin male headers, minimizing the risk of accidental disconnection caused by vibration or movement.

Whether you're assembling custom wire harnesses, repairing electronic devices, or building embedded systems, the 3 Pin JST PH 2.0mm Housing provides a durable and dependable connector solution.

Key Features

• JST PH 2.0mm compatible housing
• 3-pin wire-to-board connector
• 2.0mm pitch
• Polarized design prevents incorrect insertion
• Compatible with JST PH crimp terminals
• Secure locking mechanism for reliable connections
• High-strength PA66 (Nylon) insulating housing
• Compact design for space-constrained applications
• Easy terminal insertion and assembly
• Durable construction for long service life

Applications & Use Cases

The 3 Pin JST PH 2.0mm Housing is commonly used in:

• Drones and UAV electronics
• Battery Management Systems (BMS)
• Robotics and automation
• IoT devices
• Sensor modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial electronic equipment
• DIY electronics and custom cable assemblies

Technical Specifications

• Connector Type: JST PH Compatible Housing
• Number of Pins: 3
• Pitch: 2.0mm
• Housing Material: PA66 (Nylon)
• Color: White/Natural
• Mounting Style: Wire-to-board
• Terminal Type: Compatible with JST PH crimp terminals (sold separately)
• Compatible Header: JST PH 2.0mm 3-pin male header
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A (depending on terminals and wire gauge)
• Operating Temperature: -25°C to +85°C

Why Choose This Housing?

The 3 Pin JST PH 2.0mm Housing is an excellent choice for creating compact and reliable wire harnesses. Its polarized design ensures correct mating, while the durable nylon construction provides long-lasting mechanical strength and electrical insulation. Compatible with standard JST PH terminals and headers, it is ideal for drones, robotics, battery-powered devices, and a wide range of electronic projects.

Package Includes

• 1 × 3 Pin JST PH 2.0mm Housing

The 3 pin JST PH connector with a 2mm pitch and Teflon PTFE insulation offers reliable connections for electronic projects requiring secure signal and power transfer. Featuring a one-side female design and a 15cm wire length, this connector is ideal for linking PCBs to wires or other boards. Its durable materials ensure consistent performance in various applications, making it a versatile choice for electronics assemblies and prototyping.

• Compact 2mm pitch design ensures precise and secure connections in tight spaces
• Teflon PTFE insulation provides excellent heat resistance and electrical insulation
• One side female connector simplifies quick disconnects and signal transfers
• 15cm length wire offers flexibility for diverse wiring configurations and layouts
• Compatible with multiple PCB and wire applications for versatile electronics use
• Reliable transmission of both power and signals between boards and components
• Ideal for hobbyist and professional electronics projects requiring robust connectivity

Product Description

The 3 Pin JST PH 2.0mm Both Side Female 30cm Cable is a high-quality pre-crimped wire harness designed to provide secure and reliable wire-to-board connections between two compatible JST PH 2.0mm male headers. Featuring 3-pin JST PH 2.0mm female connectors on both ends and a 30cm cable length, this ready-to-use cable simplifies wiring, reduces assembly time, and ensures dependable electrical performance.

Compatible with the JST PH 2.0mm series, this cable is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, embedded systems, consumer electronics, and DIY electronics projects. The 30cm cable provides flexibility for routing while maintaining a clean and organized installation.

Manufactured using high-quality stranded copper conductors with durable PVC insulation, the cable offers excellent conductivity, flexibility, and long-term reliability. The factory-crimped female connectors ensure a secure fit with compatible JST PH 2.0mm male headers, reducing the risk of loose connections and signal interruptions.

Whether you're connecting controller boards, sensor modules, displays, or custom electronic assemblies, the 3 Pin JST PH 2.0mm Both Side Female 30cm Cable provides a convenient and dependable plug-and-play wiring solution.

Key Features

• JST PH 2.0mm compatible female connectors on both ends
• 3-pin configuration
• 30cm cable length
• Factory-crimped terminals for secure and reliable connections
• High-quality stranded copper conductors
• Flexible PVC insulated cable
• Low contact resistance for stable electrical performance
• Secure connector locking mechanism
• Ready-to-use wiring solution
• Suitable for compact electronic applications

Applications & Use Cases

The 3 Pin JST PH 2.0mm Both Side Female Cable is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• Battery Management Systems (BMS)
• IoT devices
• Sensor and control modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and custom cable assemblies

Technical Specifications

• Connector Type: JST PH 2.0mm Female to Female
• Number of Pins: 3
• Pitch: 2.0mm
• Cable Length: 30cm
• Cable Type: Both Side Female
• Conductor Material: Stranded Copper
• Insulation Material: PVC
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 3-pin Male Header

Why Choose This Cable?

The 3 Pin JST PH 2.0mm Both Side Female 30cm Cable is an ideal solution for applications requiring quick and reliable connections between compatible JST PH headers. Its pre-crimped connectors eliminate manual wiring effort, while the durable construction ensures consistent performance in drones, robotics, embedded electronics, and other compact electronic systems.

Package Includes

• 1 × 3 Pin JST PH 2.0mm Both Side Female 30cm Cable

The 20cm JST PH 2.0mm both side crimped wire in white is designed for creating customizable dual-ended connectors with ease. Ideal for connecting electronic components, this wire suits various applications requiring precise and reliable connections. Its 2.0mm pitch and compatibility with JST PH housings ensure secure and efficient connectivity in compact setups. Perfect for DIY electronics, prototyping, or repairing devices where dependable wiring solutions are essential.

• Dual-sided crimped ends allow quick insertion into housings on both sides, simplifying assembly.
• 20cm length provides versatile reach for a wide range of wiring tasks without excess bulk.
• 2.0mm pitch matches standard JST PH connectors for seamless compatibility.
• White insulation offers clear visibility and identification within wiring harnesses.
• Constructed with quality materials to deliver consistent electrical performance and durability.
• Ideal for electronics hobbyists, engineers, and technicians working on compact circuit connections.

This 2 pin JST PH connector features a 2mm pitch and is equipped with a durable Teflon PTFE wire measuring 15cm on one female side. Designed for reliable PCB-to-wire connections, it facilitates quick disconnects and seamless signal or power transfer between boards or from board to wire, making it ideal for compact electronic projects and component assemblies requiring precision and flexibility.

• 2mm pitch ensures a compact and secure connection for tight electronic layouts.
• Teflon PTFE insulation provides excellent heat resistance and durability for long-lasting performance.
• 15cm length allows flexible routing and easy integration into various electronic assemblies.
• Female connector on one side offers straightforward compatibility with corresponding male JST PH plugs.
• Designed specifically for quick disconnect applications, simplifying maintenance and replacement tasks.
• Ideal for transferring both signal and power safely between PCBs and wires.
• Perfect for use in small-scale electronic projects, sensors, and portable devices requiring reliable connectivity.

Product Description

The 2 Pin JST PH 2.0mm Housing is a high-quality wire-to-board connector housing designed for secure and reliable electrical connections in compact electronic applications. Compatible with the JST PH 2.0mm series, this 2-pin housing is ideal for use in drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, consumer electronics, and DIY electronics projects.

Designed to accommodate 2 crimp terminals (sold separately), the housing provides a secure, polarized connection that prevents incorrect mating and ensures stable electrical performance. Its compact design makes it suitable for high-density wiring applications where space is limited while maintaining excellent connection reliability.

Manufactured from high-quality PA66 (Nylon) thermoplastic, the housing offers excellent mechanical strength, electrical insulation, and resistance to heat and wear. The locking design securely mates with compatible JST PH 2.0mm 2-pin male headers, minimizing the risk of accidental disconnection caused by vibration or movement.

Whether you're assembling custom wire harnesses, repairing electronic devices, or building embedded systems, the 2 Pin JST PH 2.0mm Housing provides a durable and dependable connector solution.

Key Features

• JST PH 2.0mm compatible housing
• 2-pin wire-to-board connector
• 2.0mm pitch
• Polarized design prevents incorrect insertion
• Compatible with JST PH crimp terminals
• Secure locking mechanism for reliable connections
• High-strength PA66 (Nylon) insulating housing
• Compact design for space-constrained applications
• Easy terminal insertion and assembly
• Durable construction for long service life

Applications & Use Cases

The 2 Pin JST PH 2.0mm Housing is commonly used in:

• Drones and UAV electronics
• Battery Management Systems (BMS)
• Robotics and automation
• IoT devices
• Sensor modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial electronic equipment
• DIY electronics and custom cable assemblies

Technical Specifications

• Connector Type: JST PH Compatible Housing
• Number of Pins: 2
• Pitch: 2.0mm
• Housing Material: PA66 (Nylon)
• Color: White/Natural
• Mounting Style: Wire-to-board
• Terminal Type: Compatible with JST PH crimp terminals (sold separately)
• Compatible Header: JST PH 2.0mm 2-pin male header
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A (depending on terminals and wire gauge)
• Operating Temperature: -25°C to +85°C

Why Choose This Housing?

The 2 Pin JST PH 2.0mm Housing is an excellent choice for creating compact and reliable wire harnesses. Its polarized design ensures correct mating, while the durable nylon construction provides long-lasting mechanical strength and electrical insulation. Compatible with standard JST PH terminals and headers, it is ideal for drones, robotics, battery-powered devices, and a wide range of electronic projects.

Package Includes

• 1 × 2 Pin JST PH 2.0mm Housing

Product Description

The 2 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry is a compact and reliable surface-mount wire-to-board connector designed for secure electrical connections in space-constrained electronic applications. Featuring a 2.0mm pitch, 2-pin configuration, and vertical straight top-entry design, this connector is suitable for applications requiring a compact PCB-mounted connection solution.

Compatible with the JST PH 2.0mm series, this header is designed for Surface Mount Technology (SMT) assembly, making it ideal for automated PCB manufacturing and high-density circuit board layouts. The vertical top-entry orientation allows the mating connector to connect directly from above the PCB, helping optimize board space and cable arrangement.

The connector is manufactured with high-quality copper alloy contacts with tin plating, ensuring excellent electrical conductivity, low contact resistance, and reliable long-term performance. Its high-temperature thermoplastic housing provides excellent insulation and durability while supporting standard SMT soldering processes.

Ideal for drones, robotics, IoT devices, sensors, embedded electronics, and consumer electronic products, the 2 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry offers a dependable and space-efficient wire-to-board connection solution.

Key Features

• JST PH 2.0mm compatible SMT header
• 2-pin wire-to-board connector
• 2.0mm pitch
• Surface Mount Technology (SMT) design
• Vertical straight top-entry orientation
• Polarized design for correct mating
• Tin-plated copper alloy contacts
• High-temperature thermoplastic housing
• Suitable for automated PCB assembly
• Compact and space-saving design
• Reliable electrical and mechanical performance

Applications & Use Cases

The 2 Pin JST PH 2.0mm SMT Vertical Header is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• IoT devices
• Sensor modules
• Battery Management Systems (BMS)
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino-compatible hardware
• Industrial control equipment
• DIY electronics and PCB prototyping

Technical Specifications

• Connector Type: JST PH Compatible SMT Header
• Number of Pins: 2
• Pitch: 2.0mm
• Mounting Type: Surface Mount Technology (SMT)
• Orientation: Vertical Straight (Top Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 2-pin Female Housing

Why Choose This Header?

The 2 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry is an excellent choice for compact PCB designs requiring a reliable vertical connection interface. Its SMT construction enables efficient automated assembly, while the polarized design ensures secure mating and consistent electrical performance. It is widely suitable for drones, robotics, embedded systems, and other space-limited electronic applications.

Package Includes

• 1 × 2 Pin JST PH 2.0mm SMT Header Vertical Straight Top Entry Connector

The 2 pin JST PH 2.0mm SMT Header Horizontal Right Angle Side Entry is a precise connector designed for reliable PCB-to-wire connections. This compact component facilitates quick disconnects and signal or power transfers between circuit boards and wires. Its surface-mount technology and right-angle design ensure space-efficient mounting, making it ideal for applications where board-to-wire interfacing demands a low-profile, robust connection.

• 2.0mm pitch provides a compact and secure connection between PCB and wires
• Surface-mount technology ensures stable soldering and streamlined assembly on circuit boards
• Right-angle side entry orientation optimizes space utilization in tight electronic assemblies
• Designed for both signal and power transmission, suitable for versatile electronic uses
• Quick disconnect capability allows for easy maintenance and component replacement
• Compatible with various wire harnesses and PCB layouts requiring reliable connectivity

The 2 pin JST PH connector with a 2.0mm pitch offers a reliable solution for quick disconnection and signal or power transfer between printed circuit boards and wires. This version features female connectors on both sides with a 10cm wire length, making it ideal for compact and efficient electronic assemblies. Engineered for compatibility with standard JST PH components, it suits a variety of applications requiring secure connections in tight spaces.

• 2.0mm pitch spacing ensures consistent and secure electrical contact between components.
• Female connectors on both ends facilitate easy connection to matching male pins on boards or wires.
• 10cm cable length offers flexibility for routing and integration into electronic projects.
• Designed for straightforward PCB-to-wire or board-to-board connections, simplifying assembly and maintenance.
• Compact profile fits well within space-constrained electronic devices and circuits.
• Durable construction supports reliable signal and power transfer under typical operating conditions.

Product Description

The 12 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry is a high-quality PCB-mounted wire-to-board connector designed to provide secure and reliable electrical connections in compact electronic systems. Featuring a 2.0mm pitch, 12-pin configuration, and vertical straight top-entry design, this connector is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, consumer electronics, industrial control systems, and embedded electronics.

Compatible with the JST PH 2.0mm series, this header is designed for through-hole (THT) PCB mounting, providing excellent mechanical strength and long-term durability. The vertical top-entry orientation allows cables to connect directly from above the PCB, making it suitable for applications requiring efficient cable management and vertical board-to-wire connections.

The connector features high-quality copper alloy contacts with tin plating, ensuring low contact resistance, reliable electrical conductivity, and excellent corrosion resistance. Its high-temperature thermoplastic housing offers superior insulation and withstands soldering temperatures, making it suitable for both prototype development and mass production.

Whether you're designing a multi-signal PCB, assembling a drone controller, or building industrial and embedded electronic systems, the 12 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry provides a compact, reliable, and durable wire-to-board connection solution.

Key Features

• JST PH 2.0mm compatible PCB header
• 12-pin wire-to-board connector
• 2.0mm pitch
• Through-hole (THT) PCB mounting
• Vertical straight top-entry design
• Polarized connector prevents incorrect mating
• Tin-plated copper alloy contacts
• High-temperature thermoplastic housing
• Strong mechanical retention after soldering
• Compact and reliable design
• Easy installation and dependable electrical performance

Applications & Use Cases

The 12 Pin JST PH 2.0mm Vertical Header is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• Battery Management Systems (BMS)
• IoT devices
• Sensor and control modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and PCB prototyping

Technical Specifications

• Connector Type: JST PH Compatible Header
• Number of Pins: 12
• Pitch: 2.0mm
• Mounting Type: Through-Hole (THT)
• Orientation: Vertical Straight (Top Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 12-pin Female Housing

Why Choose This Header?

The 12 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry is ideal for applications requiring multiple signal or power connections in a compact PCB layout. Its through-hole construction provides excellent mechanical stability, while the polarized design ensures secure and reliable mating. Suitable for drones, robotics, industrial electronics, and embedded systems, it delivers consistent performance and long-term durability.

Package Includes

• 1 × 12 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry Connector

Product Description

The 12 Pin JST PH 2.0mm One Side Female 30cm Cable is a high-quality pre-crimped wire harness designed to provide reliable wire-to-board connections for a wide range of electronic applications. Featuring a 12-pin JST PH 2.0mm female connector on one end and 30cm pre-stripped/tinned flying leads on the other, this cable simplifies wiring and reduces assembly time for prototyping and production.

Designed for compatibility with JST PH 2.0mm headers, this cable is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, embedded systems, consumer electronics, and DIY electronics projects. The 30cm cable length offers flexibility for internal wiring while maintaining a clean and organized installation.

The cable is manufactured using high-quality stranded copper conductors with durable PVC insulation, providing excellent electrical conductivity, flexibility, and long-term reliability. The factory-crimped JST PH female housing ensures a secure and stable connection with compatible male headers, minimizing the risk of loose contacts.

Whether you're building custom cable assemblies, connecting sensor modules, or prototyping electronic circuits, the 12 Pin JST PH 2.0mm One Side Female 30cm Cable offers a convenient and dependable wiring solution.

Key Features

• JST PH 2.0mm compatible female connector
• 12-pin configuration
• 30cm cable length
• Female connector on one end with flying leads on the other
• Factory-crimped terminals for secure connections
• High-quality stranded copper wire
• Flexible PVC insulation
• Excellent electrical conductivity
• Durable and reliable construction
• Ready-to-use for quick installation

Applications & Use Cases

The 12 Pin JST PH 2.0mm One Side Female Cable is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• Battery Management Systems (BMS)
• IoT devices
• Sensor modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and custom wiring harnesses

Technical Specifications

• Connector Type: JST PH 2.0mm Female
• Number of Pins: 12
• Pitch: 2.0mm
• Cable Length: 30cm
• Cable Type: One Side Female with Flying Leads
• Conductor Material: Stranded Copper
• Insulation Material: PVC
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Header: JST PH 2.0mm 12-pin Male Header

Why Choose This Cable?

The 12 Pin JST PH 2.0mm One Side Female 30cm Cable is an ideal solution for projects requiring quick, reliable, and organized wire-to-board connections. Its factory-crimped female connector, flexible 30cm cable, and durable construction make it perfect for drones, robotics, embedded systems, and industrial electronics, eliminating the need for manual crimping and simplifying installation.

Package Includes

• 1 × 12 Pin JST PH 2.0mm One Side Female 30cm Cable

The 10cm JST PH 2.0mm both side crimped wire in white enables secure, custom wiring solutions for electronic projects. Designed with a 2.0mm pitch, it easily fits compatible JST PH connectors, allowing for straightforward two-sided crimping. This wire is ideal for creating tailored connections in various components, offering flexibility in wiring length and configuration to suit your specific application needs.

• 10cm length offers convenient wiring without excess bulk for neat installations
• 2.0mm pitch compatibility ensures seamless integration with JST PH connector housings
• Both side crimped ends simplify the process of making custom two-sided connections
• White insulation provides clear visibility and easy identification in wiring setups
• Flexible enough for use in various electronic assemblies and component connections
• Precision manufacturing guarantees reliable electrical contact and consistent performance
• Compatible with multiple connector counts, allowing tailored connector housing insertion

Product Description

The 10 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry is a high-quality PCB-mounted wire-to-board connector designed to provide secure and reliable electrical connections in compact electronic systems. Featuring a 2.0mm pitch, 10-pin configuration, and vertical straight top-entry design, this connector is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, consumer electronics, industrial control systems, and embedded electronics.

Compatible with the JST PH 2.0mm series, this header is designed for through-hole (THT) PCB mounting, providing excellent mechanical strength and long-term durability. The vertical top-entry orientation allows cables to connect directly from above the PCB, making it suitable for applications requiring efficient cable management and vertical board-to-wire connections.

The connector features high-quality copper alloy contacts with tin plating, ensuring low contact resistance, reliable electrical conductivity, and excellent corrosion resistance. Its high-temperature thermoplastic housing offers superior insulation and withstands soldering temperatures, making it suitable for both prototype development and mass production.

Whether you're designing a multi-signal PCB, assembling a drone controller, or building industrial and embedded electronic systems, the 10 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry provides a compact, reliable, and durable wire-to-board connection solution.

Key Features

• JST PH 2.0mm compatible PCB header
• 10-pin wire-to-board connector
• 2.0mm pitch
• Through-hole (THT) PCB mounting
• Vertical straight top-entry design
• Polarized connector prevents incorrect mating
• Tin-plated copper alloy contacts
• High-temperature thermoplastic housing
• Strong mechanical retention after soldering
• Compact and reliable design
• Easy installation and dependable electrical performance

Applications & Use Cases

The 10 Pin JST PH 2.0mm Vertical Header is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• Battery Management Systems (BMS)
• IoT devices
• Sensor and control modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and PCB prototyping

Technical Specifications

• Connector Type: JST PH Compatible Header
• Number of Pins: 10
• Pitch: 2.0mm
• Mounting Type: Through-Hole (THT)
• Orientation: Vertical Straight (Top Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 10-pin Female Housing

Why Choose This Header?

The 10 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry is ideal for applications requiring multiple signal or power connections in a compact PCB layout. Its through-hole construction provides excellent mechanical stability, while the polarized design ensures secure and reliable mating. Suitable for drones, robotics, industrial electronics, and embedded systems, it delivers consistent performance and long-term durability.

Package Includes

• 1 × 10 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry Connector

The 10 pin JST PH 2.0mm SMT Header with a horizontal right angle side entry is designed for secure and efficient connections between PCBs and wires. This connector facilitates quick disconnects and reliable signal or power transfer, ideal for compact electronic assemblies. Featuring a 2.0mm pitch and surface-mount technology, it supports precise alignment and stable mounting, making it suitable for various low-voltage electronic applications requiring dependable interconnections.

• 10-pin configuration provides multiple connection points for versatile wiring needs.
• 2.0mm pitch ensures compact spacing ideal for tight PCB layouts.
• Surface-mount technology (SMT) supports automated assembly and robust soldering.
• Horizontal right angle side entry allows for streamlined cable routing in space-constrained setups.
• Designed to enable quick disconnects, simplifying maintenance and component replacement.
• Compatible with a wide range of electronic boards for seamless integration.
• Delivers reliable signal and power transfer in low-voltage circuits.

Product Description

The 10 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry is a high-quality PCB-mounted wire-to-board connector designed to provide secure and reliable electrical connections in compact electronic systems. Featuring a 2.0mm pitch, 10-pin configuration, and horizontal right-angle side-entry design, this connector is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, consumer electronics, industrial control systems, and embedded electronics.

Compatible with the JST PH 2.0mm series, this header is designed for through-hole (THT) PCB mounting, providing excellent mechanical strength and long-term durability. The horizontal right-angle orientation allows cables to connect parallel to the PCB, making it ideal for applications requiring low-profile cable routing and compact enclosure designs.

The connector features high-quality copper alloy contacts with tin plating, ensuring low contact resistance, reliable electrical conductivity, and excellent corrosion resistance. Its high-temperature thermoplastic housing offers superior insulation and withstands soldering temperatures, making it suitable for both prototype development and mass production.

Whether you're designing a drone flight controller, building an embedded system, or assembling industrial electronic equipment, the 10 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry provides a compact, durable, and dependable wire-to-board connection solution.

Key Features

• JST PH 2.0mm compatible PCB header
• 10-pin wire-to-board connector
• 2.0mm pitch
• Through-hole (THT) PCB mounting
• Horizontal right-angle side-entry design
• Polarized connector prevents incorrect mating
• Tin-plated copper alloy contacts
• High-temperature thermoplastic housing
• Strong mechanical retention after soldering
• Compact, low-profile design
• Reliable electrical performance and easy installation

Applications & Use Cases

The 10 Pin JST PH 2.0mm Right Angle Header is commonly used in:

• Drones and UAV electronics
• Robotics and automation
• Battery Management Systems (BMS)
• IoT devices
• Sensor modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and PCB prototyping

Technical Specifications

• Connector Type: JST PH Compatible Header
• Number of Pins: 10
• Pitch: 2.0mm
• Mounting Type: Through-Hole (THT)
• Orientation: Horizontal Right Angle (Side Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 10-pin Female Housing

Why Choose This Header?

The 10 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry is an excellent choice for compact PCB layouts requiring side-entry cable routing. Its through-hole construction provides superior mechanical stability, while the polarized design ensures secure and reliable mating. Ideal for drones, robotics, industrial electronics, and embedded systems, it delivers dependable performance and long service life.

Package Includes

• 1 × 10 Pin JST PH 2.0mm Through Hole Header Horizontal Right Angle Side Entry Connector

Product Description

The 10 Pin JST PH 2.0mm Both Side Female 30cm Cable is a high-quality pre-crimped wire harness designed to provide secure and reliable wire-to-board connections between two compatible JST PH 2.0mm male headers. Featuring 10-pin JST PH 2.0mm female connectors on both ends and a 30cm cable length, this ready-to-use cable simplifies wiring, reduces assembly time, and ensures dependable electrical performance.

Compatible with the JST PH 2.0mm series, this cable is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, embedded systems, consumer electronics, and DIY electronics projects. The 30cm cable provides ample length for flexible routing while maintaining a clean and organized installation.

Manufactured using high-quality stranded copper conductors with durable PVC insulation, the cable offers excellent conductivity, flexibility, and long service life. The factory-crimped female connectors ensure a secure fit with compatible male headers, minimizing the risk of loose or intermittent connections.

Whether you're connecting controller boards, sensor modules, displays, or custom electronic assemblies, the 10 Pin JST PH 2.0mm Both Side Female 30cm Cable provides a reliable and convenient plug-and-play wiring solution.

Key Features

• JST PH 2.0mm compatible female connectors on both ends
• 10-pin configuration
• 30cm cable length
• Factory-crimped terminals for reliable connections
• High-quality stranded copper conductors
• Flexible and durable PVC insulation
• Excellent electrical conductivity
• Secure and stable connector fit
• Ready-to-use—no crimping required
• Ideal for compact electronic assemblies

Applications & Use Cases

The 10 Pin JST PH 2.0mm Both Side Female Cable is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• Battery Management Systems (BMS)
• IoT devices
• Sensor and control modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and custom wiring harnesses

Technical Specifications

• Connector Type: JST PH 2.0mm Female to Female
• Number of Pins: 10
• Pitch: 2.0mm
• Cable Length: 30cm
• Cable Type: Both Side Female
• Conductor Material: Stranded Copper
• Insulation Material: PVC
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 10-pin Male Header

Why Choose This Cable?

The 10 Pin JST PH 2.0mm Both Side Female 30cm Cable is an ideal choice for creating reliable board-to-board or module-to-module connections without the need for soldering or manual crimping. Its factory-assembled connectors, durable cable construction, and flexible 30cm length make it perfect for drones, robotics, embedded systems, industrial electronics, and rapid prototyping.

Package Includes

• 1 × 10 Pin JST PH 2.0mm Both Side Female 30cm Cable

Product Description

The 10 Pin JST PH 2.0mm One Side Female 30cm Cable is a high-quality pre-crimped wire harness designed to provide secure and reliable wire-to-board connections for electronic applications. Featuring a 10-pin JST PH 2.0mm female connector on one end and 30cm flying leads on the other end, this cable provides a convenient solution for connecting PCBs, modules, sensors, and electronic components without requiring manual crimping.

Compatible with the JST PH 2.0mm series, this cable is widely used in drones, robotics, battery management systems (BMS), IoT devices, sensors, embedded systems, consumer electronics, and DIY electronics projects. The 30cm cable length provides flexibility for routing and installation while maintaining an organized wiring setup.

The cable is manufactured using high-quality stranded copper conductors with durable PVC insulation, offering excellent conductivity, flexibility, and long-term reliability. The factory-crimped JST PH female connector ensures a secure connection with compatible JST PH 2.0mm male headers, reducing the possibility of loose contacts and connection failures.

Whether used for custom cable assemblies, prototype development, or electronic device integration, the 10 Pin JST PH 2.0mm One Side Female 30cm Cable delivers a reliable and easy-to-install wiring solution.

Key Features

• JST PH 2.0mm compatible female connector
• 10-pin configuration
• 30cm cable length
• Female connector on one end with flying wires on the other end
• Factory-crimped terminals for secure connections
• High-quality stranded copper wires
• Flexible PVC insulation
• Compact and lightweight design
• Easy plug-and-play installation
• Reliable electrical performance

Applications & Use Cases

The 10 Pin JST PH 2.0mm One Side Female Cable is commonly used in:

• Drones and UAV electronics
• Robotics and automation systems
• Battery Management Systems (BMS)
• IoT devices
• Sensor and control modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and custom wiring harnesses

Technical Specifications

• Connector Type: JST PH 2.0mm Female Connector
• Number of Pins: 10
• Pitch: 2.0mm
• Cable Length: 30cm
• Cable Type: One Side Female with Flying Leads
• Conductor Material: Stranded Copper
• Insulation Material: PVC
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 10-pin Male Header

Why Choose This Cable?

The 10 Pin JST PH 2.0mm One Side Female 30cm Cable is an excellent choice for applications requiring a ready-made wiring solution with a secure JST connection on one side and flexible wire access on the other. Its durable construction, compact design, and reliable connector performance make it suitable for drones, robotics, embedded electronics, and custom electronic projects.

Package Includes

• 1 × 10 Pin JST PH 2.0mm One Side Female 30cm Cable

The 10 pin JST PH 2.0mm SMT Header Vertical Straight Top Entry is a compact connector designed for efficient PCB-to-wire connections. It enables quick disconnects and seamless transfer of signals and power between circuit boards and wiring harnesses. Featuring a 2.0mm pitch and surface-mount technology (SMT) for secure and space-saving mounting, this header is suitable for electronic assemblies requiring reliable connectivity and easy servicing.

• 10 pins arranged for versatile multi-signal or power transmission
• 2.0mm pitch ensures precise alignment and compatibility with JST PH series connectors
• Surface-mount design minimizes board space and enhances assembly stability
• Vertical straight top entry orientation simplifies cable routing and connection
• Ideal for quick disconnect applications between PCBs and wiring
• Durable construction supports repeated connections and disconnections
• Supports both signal and power transfer with reliable conductivity
• Compatible with a wide range of electronic devices and custom board setups

This 10-pin JST PH connector with a 2.0mm pitch offers a reliable solution for connecting PCB boards to wires or linking multiple boards. Featuring female connectors on both ends and a 10cm cable length, it efficiently transfers signals and power, making it suitable for various electronic projects and devices. Its compact design ensures compatibility with standard JST PH series components, providing secure connections in compact spaces.

• Dual female connectors enable straightforward board-to-wire or board-to-board links without additional adapters
• 10-pin configuration supports multiple signal or power lines simultaneously for versatile use
• 2.0mm pitch ensures compatibility with common JST PH series headers and sockets
• 10cm cable length offers flexibility in wiring layouts while maintaining signal integrity
• Compact and lightweight design fits neatly into tight electronic assemblies without adding bulk
• Reliable quick disconnect feature simplifies maintenance and modifications in electronic systems

This 10 pin JST 1.25mm one side female connector with 30cm wires is designed for reliable low-voltage electrical connections in compact electronic projects. Its precise 1.25mm pitch ensures compatibility with a variety of JST headers, making it ideal for wiring sensors, microcontrollers, and other components. The included 30cm length wires offer flexibility in setup, while the female connector simplifies secure plug-and-play connections in tight spaces.

• 10-pin female connector with a 1.25mm pitch for precise alignment and secure connections.
• 30cm pre-attached wires provide ample length for flexible component placement.
• Compatible with standard JST 1.25mm male headers commonly used in electronics.
• Designed for compact applications requiring reliable signal and power transmission.
• Durable construction ensures stable connectivity in circuit assemblies.
• Easy to integrate into custom wiring harnesses and prototyping setups.

The 10 pin SMD JST 1.25mm Side Entry Header is a compact electronic component designed for secure and efficient connections on printed circuit boards. This side entry header features a 1.25mm pitch with 10 pins, making it ideal for tight spaces where vertical clearance is limited. Its surface-mount design ensures compatibility with modern PCB assembly techniques, providing reliable signal transfer in various electronic applications including communication devices and compact gadgets.

• 10-pin configuration supports multiple connection points within a minimal footprint
• 1.25mm pitch offers precise spacing suitable for fine-pitch PCB layouts
• Side entry design allows connections parallel to the board surface, optimizing space usage
• Surface-mount technology (SMD) enables automated placement and soldering for efficient manufacturing
• Durable construction ensures stable electrical connections under frequent plugging cycles
• Compatible with JST connector systems for easy integration with matching plugs and cables
• Ideal for compact electronics such as communication modules and embedded systems

The 10 pin JST 1.25mm Through Hole Header Horizontal Right Angle is a reliable electronic component designed for secure connections in circuit boards. Its 1.25mm pitch and ten-pin configuration provide precise alignment and durability. This right-angle header fits through-hole mounting applications, making it ideal for compact spaces and various electronic assemblies. Compatible with standard JST connectors, it ensures consistent performance in both prototype and production environments.

• 1.25mm pin spacing ensures compact connection points, saving board space
• Ten-pin layout provides multiple connection channels for versatile circuit designs
• Right-angle orientation allows for efficient horizontal board mounting in tight areas
• Through-hole design offers strong mechanical stability for long-term reliability
• Compatible with standard JST connectors for seamless integration into existing setups
• Constructed with durable materials to withstand regular insertion and removal cycles
• Ideal for use in electronics prototyping, repair, and production applications

The 10 pin JST XH 2.5mm to Pin Entry Header is a durable electronic component designed to provide secure and reliable connections in various wiring assemblies. Featuring a 2.5mm pitch, this connector facilitates easy mating with compatible JST XH cables, making it ideal for applications requiring stable signal transmission. Its 10-pin configuration supports multiple connections in compact spaces, ensuring versatility across different electronic projects and devices.

• 10-pin design allows multiple circuits to be connected simultaneously in a compact form factor.
• 2.5mm pitch spacing ensures compatibility with standard JST XH connectors for consistent connectivity.
• Pin entry header type provides straightforward soldering and mounting options on printed circuit boards.
• Engineered for reliable electrical contact, minimizing resistance and signal loss in critical connections.
• Suitable for use in electronic assemblies, prototyping, and repair projects requiring dependable wire-to-board connections.

The 10 pin JST 1.25mm Housing is a reliable connector component designed for secure and compact electronic connections. Ideal for applications requiring precise pin spacing, this housing supports up to 10 pins with a 1.25mm pitch, making it suitable for tight circuit layouts. Its durable construction ensures consistent performance in various electronic assemblies, enhancing signal integrity and connection stability across compatible JST connectors.

• Engineered with a 1.25mm pitch to fit compact circuit designs without sacrificing reliability
• Accommodates 10 pins for versatile multi-connection setups in electronic devices
• Constructed from high-quality materials to provide robust mechanical strength and electrical insulation
• Designed for seamless compatibility with corresponding JST terminals and connectors
• Compact housing shape optimizes space usage in dense electronic assemblies
• Supports dependable signal transmission, reducing risk of connection failures

This 10 pin JST XH connector with a 2.5mm pitch features a one-sided female design paired with 30cm long wires, making it ideal for reliable electrical connections in various electronic components. Its compatibility with JST XH series connectors ensures secure and efficient signal or power transmission in DIY electronics, robotics, and other component assemblies requiring precise connectivity.

• 10-pin configuration provides multiple connection points suitable for complex wiring setups.
• 2.5mm pitch spacing ensures compatibility with standard JST XH series components for seamless integration.
• One side female connector design offers straightforward plug-in connections to male counterparts.
• 30cm wire length allows flexibility in positioning components within electronic projects.
• The wires are pre-attached to the connector, simplifying installation and reducing assembly time.
• Compact and lightweight, making it suitable for use in tight spaces without adding bulk.
• Designed for secure and stable electrical contact to maintain consistent performance.

The 10 pin JST 1.25mm Through Hole Header Vertical Straight is a compact electronic component designed for reliable circuit connections. Featuring a 1.25mm pin spacing and through-hole mounting style, it enables secure attachment to printed circuit boards. This vertical straight header suits a wide range of electronic assemblies where space efficiency and dependable connectivity are essential. Its standard 10-pin configuration supports various wiring and interfacing applications in electronics projects and devices.

• 1.25mm pin pitch ensures precise alignment and compatibility with JST connectors
• Through-hole design offers strong mechanical stability for circuit boards
• Vertical straight orientation simplifies soldering and layout in compact assemblies
• 10-pin configuration supports multi-wire connections for diverse electronic setups
• Durable materials maintain consistent electrical contact over extended use
• Ideal for prototyping, repairs, and custom electronic projects
