Amass XT30UPB-M30.N.B – XT30UPB Male Connector (Nickel-Plated, Black)

Product Description

The Amass XT30UPB-M30.N.B (XT30UPB Male Connector – Nickel-Plated, Black) is a premium PCB-mounted high-current DC power connector designed for compact and reliable power delivery in FPV drones, RC aircraft, robotics, battery management systems (BMS), power distribution boards, and embedded electronic systems. Manufactured by Amass, a globally trusted connector brand, this XT30UPB series is widely used where direct PCB integration and stable high-current performance are required.

The XT30UPB-M30.N.B Male Connector features nickel-plated brass contacts that provide good electrical conductivity, corrosion resistance, and stable long-term performance. The nickel plating helps maintain durability in repeated mating cycles while ensuring consistent current transfer in demanding electronic applications.

Designed for through-hole PCB mounting (THT), the connector is soldered directly onto the PCB, making it ideal for compact power distribution layouts where wired connectors would take more space. Its straight vertical structure ensures firm mechanical anchoring, reducing stress on solder joints during vibration-heavy applications like drones and RC systems.

The connector is rated for 15A continuous current and 500V DC, making it suitable for low-to-medium power battery systems and ESC connections. It uses a 2-pin configuration (positive and negative) and is designed to maintain low contact resistance for efficient power flow in compact systems.

The housing is made from high-temperature PA (Nylon/Polyamide) with UL94 V-0 flame-retardant rating, ensuring strong thermal stability, electrical insulation, and resistance to mechanical stress. Its black color gives a clean, professional look suitable for integrated PCB designs in drones and industrial electronics.

Whether you're designing a drone power distribution board, building a compact LiPo battery system, or integrating power into a robotics PCB, the Amass XT30UPB-M30.N.B Male Connector offers a reliable, space-efficient, and durable solution.

Key Features

• Genuine Amass XT30UPB-M30.N.B Male PCB Connector
• PCB-mounted (Through-Hole / THT) design
• Nickel-plated brass contacts for durability and corrosion resistance
• Rated for 15A continuous current
• Rated for 500V DC
• Compact 2-pin high-current power connector
• High-temperature PA66 (Nylon) housing
• UL94 V-0 flame-retardant material
• Stable mechanical anchoring for vibration-prone systems
• Designed for drone, RC, and embedded PCB power systems

Applications & Use Cases

• FPV drones and racing drones
• RC aircraft and ground vehicles
• Power Distribution Boards (PDBs)
• Battery Management Systems (BMS)
• Lithium battery packs
• Embedded electronics and IoT power systems
• Robotics and automation PCBs
• ESC and motor controller boards
• Compact industrial electronics

Technical Specifications

• Brand: Amass
• Model: XT30UPB-M30.N.B
• Connector Type: Male
• Series: XT30UPB
• Mounting Type: PCB Through-Hole (THT)
• Contact Material: Brass
• Contact Plating: Nickel
• Housing Material: PA66 (Nylon), UL94 V-0
• Rated Current: 15A
• Rated Voltage: 500V DC
• Number of Pins: 2
• Orientation: Straight vertical PCB mount
• Mechanical Durability: ~1000 mating cycles
• Operating Temperature: -20°C to 120°C

Why Choose This Connector?

The XT30UPB-M30.N.B is ideal when you want a direct PCB power input/output solution instead of bulky wired connectors. It keeps designs compact, reduces wiring complexity, and provides reliable current handling for small-to-medium drone and robotics power systems.

Package Includes

• 1 × Amass XT30UPB-M30.N.B – XT30UPB Male Connector (Nickel-Plated, Black)
