Amass XT30AW-M Male Connector – Gold-Plated Yellow XT30

Amass XT30AW-M Male Connector – Gold-Plated Yellow XT30 PCB Connector

The Amass XT30AW-M Male Connector is a compact 2-pin power connector designed for reliable PCB-mounted electrical connections in drones, RC models, battery systems, robotics, and other compact electronic applications. It features a yellow polyamide housing with gold-flash-plated brass contacts for dependable electrical conductivity and corrosion resistance.

Designed for through-hole (THT) PCB mounting, the XT30AW-M provides a practical solution where a secure and space-efficient power connection is required. Its compact XT30 form factor makes it suitable for applications where board space is limited while maintaining a robust mechanical connection.

Key Features of Amass XT30AW-M

• 2-Pin Male Connector: Designed for DC power connections in compact electronic systems.
• PCB Mount Design: Suitable for direct through-hole mounting on printed circuit boards.
• Gold-Plated Contacts: Brass contacts with gold-flash plating provide reliable conductivity and improved resistance to oxidation.
• Compact XT30 Design: Small connector format for space-constrained drone, RC, and electronics applications.
• Yellow Housing: Easy visual identification in wiring and power systems.
• Flame-Retardant Housing: Polyamide housing is rated UL94V-0 according to the manufacturer's specifications.
• Durable Construction: Designed for repeated mating and unmating, with mechanical durability specified at approximately 1,000 cycles.

Technical Specifications

Applications

The XT30AW-M male connector is suitable for a wide range of compact power and electronics applications, including:

• FPV drones and UAV power systems
• RC cars, aircraft, boats, and other RC models
• LiPo battery-powered electronics
• Drone power distribution boards
• Robotics and automation projects
• Battery management systems
• Custom PCB power connections
• DIY electronics and embedded systems

Why Choose the XT30AW-M Connector?

Reliable power connections are essential in battery-powered electronics, particularly in drones and RC systems where vibration, repeated connection cycles, and compact installation can place additional demands on connectors. The Amass XT30AW-M combines a compact PCB-mount design with gold-plated brass contacts and a flame-retardant housing.

Its standardized XT30 form factor also makes it useful when designing or repairing power connections around compatible XT30-series components. Before installation, verify connector compatibility, polarity, PCB footprint, current requirements, and the specifications of the mating connector for your application.

Installation Information

The XT30AW-M is designed for through-hole PCB mounting. Solder the connector securely to the PCB using an appropriate soldering process and inspect the joints for proper wetting and mechanical strength before connecting a power source.

Always confirm polarity and electrical specifications before powering the assembled circuit. Incorrect polarity or an unsuitable mating connector can damage connected electronic components.

Package Includes

• 1 × Amass XT30AW-M Male Connector

Frequently Asked Questions

What is the Amass XT30AW-M?

The Amass XT30AW-M is a 2-pin male XT30-series power connector designed for direct PCB mounting. It is commonly used in drones, RC models, battery systems, robotics, and compact electronic devices.

Is the XT30AW-M a PCB-mount connector?

Yes. The XT30AW-M is designed for PCB mounting using a through-hole soldering configuration.

What is the current rating of the XT30AW-M?

The manufacturer's specification lists the XT30AW-M at up to 20A maximum current under specified conditions. Always consider the actual wire, PCB, thermal conditions, and application requirements when designing a power system.

What material are the XT30AW-M contacts made from?

The contacts are made from brass and feature gold-flash plating, which helps provide reliable electrical contact and resistance to oxidation.

Where can the XT30AW-M be used?

The connector can be used in FPV drones, UAVs, RC vehicles, LiPo-powered systems, robotics, battery modules, power distribution boards, and custom electronics projects requiring a compatible XT30 PCB connection.

What is the colour of the XT30AW-M?

The XT30AW-M has a yellow housing, making it easy to identify in power and wiring assemblies.
