4 pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry

Product Description

The 4 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry is a high-quality PCB-mounted wire-to-board connector designed to provide secure and reliable electrical connections in compact electronic systems. Featuring a 2.0mm pitch, 4-pin configuration, and vertical straight top-entry design, this connector is ideal for drones, robotics, battery management systems (BMS), IoT devices, sensors, LED lighting, consumer electronics, and embedded systems.

Compatible with the JST PH 2.0mm series, this header is designed for through-hole (THT) PCB mounting, offering excellent mechanical strength and durability. The vertical top-entry orientation allows cables to connect directly from above the PCB, making it suitable for applications where vertical cable routing and efficient board layout are required.

The connector features high-quality copper alloy contacts with tin plating, ensuring low contact resistance, reliable conductivity, and excellent corrosion resistance. Its high-temperature thermoplastic housing provides superior electrical insulation and withstands soldering temperatures, making it suitable for both prototyping and production applications.

Whether you're building a drone flight controller, designing an embedded system, or creating custom electronic hardware, the 4 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry offers a compact, durable, and dependable wire-to-board connection solution.

Key Features

• JST PH 2.0mm compatible PCB header
• 4-pin wire-to-board connector
• 2.0mm pitch
• Through-hole (THT) PCB mounting
• Vertical straight top-entry design
• Polarized connector prevents incorrect mating
• Tin-plated copper alloy contacts
• High-temperature thermoplastic housing
• Strong mechanical retention after soldering
• Compact and reliable design
• Easy installation and dependable electrical performance

Applications & Use Cases

The 4 Pin JST PH 2.0mm Vertical Header is commonly used in:

• Drones and UAV electronics
• Robotics and automation
• Battery Management Systems (BMS)
• IoT devices
• Sensor modules
• LED lighting systems
• Consumer electronics
• Embedded systems
• Arduino and Raspberry Pi projects
• Industrial control equipment
• DIY electronics and PCB prototyping

Technical Specifications

• Connector Type: JST PH Compatible Header
• Number of Pins: 4
• Pitch: 2.0mm
• Mounting Type: Through-Hole (THT)
• Orientation: Vertical Straight (Top Entry)
• Contact Material: Copper Alloy
• Contact Plating: Tin Plated
• Housing Material: High-temperature Thermoplastic
• Rated Voltage: 100V AC/DC
• Rated Current: Up to 2A
• Operating Temperature: -25°C to +85°C
• Compatible Connector: JST PH 2.0mm 4-pin Female Housing

Why Choose This Header?

The 4 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry is an excellent choice for PCB designs requiring vertical cable connections and reliable wire-to-board interfaces. Its through-hole construction provides superior mechanical strength, while the polarized design ensures secure and accurate mating. Ideal for drones, robotics, embedded systems, and DIY electronics, it delivers dependable performance in compact electronic assemblies.

Package Includes

• 1 × 4 Pin JST PH 2.0mm Through Hole Header Vertical Straight Top Entry Connector
